Technical specifications

Antenna unit
Reflector Type
Reflector Diameter
Reflector Gain
Minimum E.I.R.P.*
of geostationary satellites)
LNB (EU)
LNB (US)
Radome diameter
Radome height
Weight (incl. radome)
Azimuth range
Elevation range
Step width
Drive system
Tracking sensor
Tracking speed
movement of ship)
Power supply
Power on satellite lock time
System
Operation temperature
Storing temperature
(for reception
Electronic Beam Forming
(at every
12 bis 36VDC, 10 to 20W
English Page 33 / 34
TV 43 / TV 44
Prime Focus
45 cm (17.7")
33 dB
49 dBW
H/V linear, universal
LH/RH circular
550 mm
550 mm
12 kg
unlimited
5-85°
0.1°
two-axis servo system
(EBF)
>12°/s / >40°/s
10 to 20 s
TV 43 / TV 44
20 to +70°C
30 to +85°C
TV 58 / TV 59
Prime Focus
60 cm (23.6")
34.8 dB
48 dBW
H/V linear, universal
LH/RH circular
710 mm
690 mm
16 kg
unlimited
5-90°
0.1°
two-axis servo system
Electronic Beam Forming
(EBF)
>12°/s / >40°/s
12 bis 36VDC, 10 to 20W
10 to 20 s
TV 58 / TV 59
20 to +70°C
30 to +85°C
