TCS TASTA IVW5211-0145 Produktinformation Kurz Seite 2

SAFETY INSTRUCTIONS
General safety instructions
Assembly, installation, commissioning and repair of
electronic devices must be carried out by qualified
electricians. Observe the latest regulations and standards
for system installations.
WARNING! Danger due to electrical shock.
Observe the safety regulations according to DIN VDE
0100, when working on main power connections of 230 V.
When installing TCS:BUS systems the general safety
regulations for telecommunication systems according
to VDE 0800 must be observed. Inter alia:
> separated cable routing of high and low voltage lines
> minimum distance of 10 cm in case of a common cable
routing,
> use of separators between high and low voltage lines within
shared cable ducts,
> use of standard telecommunication lines, e.g. J-Y (St) Y with
PRODUCT INFORMATION (BRIEF)
0.8 mm diameter,
Series TASTA for video 2-wire:BUS > already existing lines (modernisation) with deviating
cross-sections can be used in compliance with the loop
Video indoor station for hands-free talking resistance.
IVW5211-0145
Requirements to protect against lightning
CAUTION! Device damage due to overvoltage.
German / English By suitable lightning protection measures it has to be
ensured that the electric voltage of 36 V DC at each connec-
The device is to be used only with video 2-wire:BUS tion is not to be exceeded.
systems.
PRODUCT DESCRIPTION
SCOPE OF DELIVERY
Intended use
1 x Indoor station IVW5211-0145 IVW5211-0145 is a video indoor station for hands-free talking.
1 x Mounting tray with connection terminal It is suitable exclusively for operation in video 2-wire:BUS
1 x Product information (brief) systems. Type of installation: surface-mount.
1 x Instruction manual
For applications, which differ from the intended use or
goes beyond it, the manufacturer accepts no liability.
SPARE PARTS, ACCESSORIES
Tabletop device ..............................................ZIT5000-0030
Radio signal device ........................................FFL2200-0
PI_IVW5211-0145
DEVICE OVERVIEW
15
Sensor button contrast
14 Sensor button brightness
13 Call-OFF
button
12
Smart Slot
11
LED indication (red) call-OFF
10
Volume button
9 Speech button
8
LED indication (green) for
incoming calls / speaking
INDICATION AND OPERATING ELEMENTS
1 > shortly touch: adjustable in 8 steps
2 > shortly touch: video image of the front door camera is
displayed or switching-over between different cameras
3 > send control function 8, send internal call, door relase
automatic on / off or call diversion on / off configurable
> ring tone selection: internal call
4 > switch light
> ring tone selection: floor call
> ambient illumination: press for 4 sec to de-/activate the
ambient illumination
5 > open the door
> trigger light switch function, only if light switch function
is activated in the front door station
> terminate speaking: voice connection is terminated
automatically after 4 sec
> ring tone selection: door call 1 from front door station
6 > LED off: door opener in standby
> LED on: door release automatic activated
> LED lights up for 3 sec: door is opened
> ambient illumination is on, operational readiness
7 > LED blinks: call indication, if configured
> LED off: temporary (manually) or permanently switched off
> LED on: temporary (manually) or permanently switched on
8 > LED off: in standby
> LED on: call, speaking activated
> LED blinks 3 x: speech channel is busy
9 > shortly press: call acceptance, speaking activated
> press for 2 sec: duplex communication is activated
> terminate speaking
> ring tone selection: door call 2 from front door station
10 > ring tone volume can be adjusted in 4 steps, if no voice
connection is established
> volume voice output can be adjusted in 4 steps, when a
voice connection is established
11 > LED off: call-OFF deactivated
> LED on: call-OFF activated
> LED blinks: ring tone programming mode
> LED flashes: call diversion activated, call-OFF deactivated
> LED turns off in longer periods: call diversion
activated, call-OFF activated
12 > for additional signalling of door calls, can be ordered
as accessory
13 > shortly press: ring tone off
> press for 8 sec: initiate / end mode ring tone selection
> terminate duplex communication
14 > shortly touch: adjustable in 8 steps
15 > shortly touch: adjustable in 8 steps
TECHNICAL SPECIFICATIONS
Supply voltage ................. +32 V DC + 2 V (supply unit
NVV1000-0400)
2-wire operation ............. input current:
I(av) = 2,0 mA
I(av max) = 150 mA
Video module .................. TFT colour
Display size ..................... 8.9 cm (3.5 Zoll)
Resolution ....................... 320 x 240 Pixel, RGB
Video signal input ........... symmetrical 1 Vss FBAS
Degree of protection ....... IP30
1
Sensor button colour
Acceptable ambient
temperature .................... - 5 ...+ 40 °C
2 Sensor button image
Housing ........................... plastics ASA
activation
Dimensions (mm)............... H 194 x W 94 x D 21 (mounting tray),
D 17 (mounting plate)
Weight ............................. 227 g (incl. mounting tray)
3 Function button
MOUNTING AND INSTALLATION
4 Light switch button
Mounting height
For an optimal operation, install the video indoor station 1.60
m (upper egde of the device) above the ground.
5 Door release button
6
LED indication (blue) for
door release
7
Ambient illumination
Install the mounting tray
Insert the lines through the cable gland. Connect the wires The error tone sounds 1 x long and 1 x short:
to the terminals. Fix the mounting > button stucks (pressed longer than 15 sec)
tray with suitable screws to the wall. > loosen the button at the device or the floor push button,
device is in standby mode again
Observe the installation position of the mounting tray.
It is marked by an arrow and the designation TOP.
Matching resistor
If the video indoor station is placed at the end of a strand or
is the only device at the video 2-wire:BUS, the matching
resistor is to be activated.
Ex works the video indoor station is not set up for the
operation at the end of the strandhtet.
Remove the device
Insert a screw driver with slight pressure into the release
opening (1). Pull off the device to the front at its upper side.
Lift the device out of the adjustment increments (2).
Snap-on the device
Put the device onto both adjustment increments of the mounting
tray (1). Press the device against the latch until it snaps on (2).
2
1
BELL BUTTON PROGRAMMING
Basic principle:
All devices at the video 2-wire:BUS have an unique serial
number. The serial number of the indoor station is allocated
to the bell button of the front door station. The allocation is
stored in the EEPROM of the front door station.
Requirements for programming:
1 > Ensure that the access to the indoor station in the flat is
granted.
> Check if the indoor station is connected to the video 2-wi-
re:BUS.
> Switch on the mains voltage. The operating LED at the power
supply and control unit is on.
2
> Check if a programming lock is set. If the programming
Remove the device Snap-on the device
lock is activated, you cannot program any bell button. To
deactivate the programming lock you need a Service Device
TCSK or the configuration software configo
Example circuit:
> For device-specific indication modes of the front door station
see product information of the front door station.
Connecting the floor push button
RUN/PROG button
Connect the floor push button to the terminals E1 – E2.
COMMISSIONING LED
Install all devices of the system completely. Check all wire
against each other on short-circuit. Switch on the mains power.
Error detection and indication
1. Control unit:
Indication error mode, if error detected: All 3 LEDs are flashing.
Switching on the programming mode of the system
Pressing any button of the device triggers the output of an
error tone. > shortly press RUN/PROG button
> LED blinks
Error tone - error causes and troubleshooting
> programming mode is activated
The error tone sounds 1 x long and 3 x short:
2. Programming via voice connection
> av- and E2-wire are exchanged or short-circuited
> exchange av- and E2-wire or remove short-circuit, > press the speech button
device is in standby mode again > shortly press the bell button
> ring tone sounds at the front door and indoor station
> press the speech or door release button
3. Control unit:
Switching off the programming mode of the system
> shortly press the RUN/PROG button
> LED lights up
> programming mode is deactivated
Deleting bell buttons
> activate the programming mode of the system, see 1
> press the button that is to be deleted for around 6 sec until
an acknowledgement tone sounds
> release the bell button
> switch off the programming mode of the system, see 3
Notes:
a) Do not press the RUN/PROG button longer than 5 sec. Otherwise
you will activate the light switch function of the front door station.
The bell button cannot be programmed. Repair:
> If the LED blinks, shortly press the RUN/PROG button to switch off
the programming mode.
> Press the RUN/PROG button only shortly to switch in the program-
ming mode.
> Program the bell button.
Not necessary, if the bell buttons have not been programmed, see
b)
deactivated
product information of the front door station.
If there sounds a Progsperr tone (long high tone followed by a long
c)
low tone) instead, the front door station is equipped with with a
programming lock. You ca deactivate the programming lock only
with the Service Device TCSK or the configuration software configo™.
Further information (parallel call with only one bell
button) can be found in the system manual, in the down-
activated
load area at www.tcsag.de or by scanning the QR code.
NOTES
Conformity
Declarations of conformity are available for
download at www.tcsag.de.
Information on disposal
Dispose the device separately from domestic waste
via a collection point for electronic scrap. Ask your
county administration for the responsible collection
point.
Dispose the parts of the packaging in collecting
tanks for cardboard and paper resp. plastics.
. Service
TM
For detailed information visit our website www.tcsag.de.
Download or scan the QR code.
