ENGLISH
4.5
5 Adjust
5.0
5.1
5.2
5.3
5.4
5.3
Direction of rotation Direction
Place monitor on pump in
accordance with. Fig. 2
The following are displayed:
Direction of rotation,
Rotary-field frequency,
Motor ON/OFF, nothing
displayed for OFF
Basic setting for starting up
Monitor: Contrast: Contrast between writing and background
on display, can be set between 1 (low
contrast) and 15 (greater contrast).
Time Out: Time passed between last operation and
automatic mode. Monitor switch-off, can be
set between 2 and 30 min.
Language: menu languages:
German, English, French, Dutch
f f
Password
f f
letter
until the last box f
If the IR Monitor is switched off and then on again, the
password will not reappear (personal code).
Warning! Once a password has been confirmed it cannot be
deleted.
The menu only appears once the correct code has been
entered in the first menu. This protects against unauthorised
alteration of the operator's address.
Entry of the address as above.
Only confirm using Yes
f f From A to the desired
—
f f f etc...
A —
f Yes f f Password
if the address entered is correct.
21
