Step 5: assembling the handlebar and computer
Attach the handlebar (3) with two allen bolts (17) and two curved washers (13).
Remove the four screws (16) from the back of the computer (1).
Connect the hand pulse cables (4) with the computer (1).
Attach the computer (1) to the mounting on the handlebar with four screws (16).
Attach the cover (7) with screws (8).
1
4
16
7R 8
3 13 17
7F
8
STEP 5
Step 6
When the installation is complete, carefully check and ensure all the screws and nuts are fastened
firmly.
Step 7: assembling the adaptor
The adaptor must be connected to the back of the device.
