Implementierte ccTalk-Befehle

Header Command
255
Factory setup and test
254
Simple poll
253
Address poll
252
Address clash
251
Address change
250
Address random
249
Request polling priority
248
Request status
246
Request manufacturer ID
245
Equipment category ID
244
Request product code
243
Request database version
242
Request serial number
241
Request software revision
240
Test solenoids
236
Read opto states
BA_v2_eagle_serial_DE_1-3
Function, No. of data bytes expected/returned
2, 20 (= "200 ms") [0/2]
0 = OK, 1 = return lever actuated,
2 = coin on string detected [0/1]
"NRI"/"CPS"
"Coin acceptor" [0/13]
"EAGLE" [0/5]
0 = remote coin database not available [0/1]
4 bytes
[0/4]/3 bytes [0/3]
"xxxyyzz" [0/7]:
xxx = SW main
yy = release
zz = revision
[1/0]
Bit 0: gate 0 (acceptance)
Bit 1: gate 1 (internal sorter)
Bit 2: gate 2 (internal sorter)
Bit 3: gate 3 (internal
Bit 4: upper gate (external sorter)
Bit 5: lower gate (external sorter)
[0/1]
Bit 0: SO1*/SP1**/TFR //
Bit 1: SO2*/SP2**/TFMR //
Bit 2: SO3*/SP3**/TFML //
Bit 3: TFR //
String optics
Bit 4: CP3 //
CP3
Bit 5: CP4 //
CP4
Bit 6: – //
CP5
Bit 7: – //
Sorter position
0 = unblocked, 1 = blocked
SO = sizing optics (measurement)
SP = Sorter position (longitudinal sorter)
TF = Tube full (left/mid-left/mid-right/right)
* if device reports error 121 (Validation sensor
blocked), bit1..3 will report state of sizing optics
(SO1..3)
** if device reports error 15 (Sorter opto blocked),
bit1..3 will report state of sorter feedback sensors
T
D
ECHNISCHE
Optionale ACMI-Abwei-
chungen für italienischen
Spielgerätemarkt
[0/0]
[0/1]
[0/1]
[1/0]
[0/0]
[0/3]
3 bytes [0/3]
sorter)/external manifold sorter
Dual Coin Entry opto
External manifold opto
ATEN
