Frechdax / Dreckspatz– specification
PROPAIN's Frechdax as well as Dreckspatz are mountainbikes.
Please find the according category in the "user handbook bicycles"
which is included in your bike delivery. Be sure to use your bicycle
only according to the "intended use" specified by the category.
If you replace parts of your bicycle, please pay special attention to
the hardware compatibility. If in doubt, please contact Propain or
your local bike dealer.
The Frechdax as well as the Dreckspatz have the following specifi-
cations:
Maximum front travel allowed:
Rear travel:*
Shock length:*
Shock travel:*
Shock mount top and bottom:*
Bottom bracket:
Break mount:
Seat post diameter:
100mm
90mm
152mm
31mm
8 x 22,2mm (front)
8 x 41mm (rear)
73mm BSA
Post Mount 140
27,7mm
Headset:
Rear wheel axle:
Chain line:
Chain guide mount:
Recommended tire size:
Maximum rider weight:

Tightening torque

The mounting bolts of the frame and suspension have to be tight-
ened according to the table below. After untightening any bolts
Propain recommends using Loctite 243 (medium) before tightening
the bolts again. Please also consider the drying time of Loctite.

Suspension*

Bearing
1)
2)
3)
ZS44
135mm x 10mm
49mm
ISCG05
16"/20"
40kg
Tightening torque
25 Nm / 18,44 ft lb
9 Nm / 6,64 ft lb
18 Nm / 13,28 ft lb
* does not apply for Dreckspatz model
