List of contents
General
For your safety
Use of the Kubata
Operation of the Kubata
Operation of the Kubata with transmission/crank
Cleaning
Maintenance and Rectifying faults
Disassembly and disposal
Product Overview
General

Intended use

Kubata is a sun protection awning that can only be used for this pur-
pose. Misuse can lead to hazards, damage or to collapse of the awning
and is not permissible. Changes, additions may only be carried out with
the written permission of Weinor. Prohibited changes to the awning will
result in voiding of the guarantee claims.
CE mark
Weinor GmbH & Co. KG declares that the
Kubata is in compliance with the basic
requirements and relevant provisions
of the EN standards. Kubata meets the
requirements of the wind resistance class
indicated in the CE conformity marks. The
requirements shall only be deemed as
having been met once the manufacturer's
instructions have been adhered to.

Noise level

In the non-assembled state, the noise level of this awning is below
70 dB(A).

Symbols used

Note/Tip
"CORRECT"
Power OFF
Function check/
visual inspection/
check
4
Kubata | 123312-0000 w | v1.5 | 2018-10-01
4
4
6
7
8
9
11
15
16
weinor GmbH & Co. KG
Mathias-Brüggen-Straße 110
50829 Köln
15
EN 13 561
Markise für die Verwendung
im Außenbereich
Windwiderstandsklasse:
Klasse 2
Read instructions,
observe details
"INCORRECT"
Power ON
Action step/
2
necessary action
For your safety
Safety symbols
Warning! Risk of electric shock
"Danger" of electric shock
Warning! Personal injury
"Danger" of personal injury.
Caution! Product and property damage

Safety instructions

Warning! Danger of electric shock due to improper
handling of electric components!
• Follow the warning instructions for the prevention of electrical shock!
• Follow the installation instructions of the included electric components!
• Work on electrical fixed installation is only permissible when conducted by
electrically skilled persons according to VDE 100!
Careful! Personal injury can result from improper
operation and use of the construction!
• Follow safety instructions in order to prevent personal injury!
• It must be assured that no children or people unable to properly assess the
risks of improper or incorrect use are permitted to operate the awning.
• Always keep the remote radio control out of reach of children!
• Observe the instructions as well as the regulation and operating instruc-
tions of the manufacturer of the drive, switch or control devices!
• The space needed for the awning to open must always be kept clear.
There is a risk of people being crushed in this space!
• For cleaning, disconnect the power supply (switch off fuses) and switch off
automatic control system when working in the movement range of the
construction in order to prevent risk of crushing or falling due to uncont-
rolled movements!
• Do not lean ascending aids (e.g. ladders) against the construction!
• Do not lean any articles (e.g. gardening devices) against the construction!
• Do not hang any articles (e. g. lamps, leads etc.) on the awning!
• Do not use a damaged awning under any circumstances! Secure a dama-
ged awning and contact a specialist company!
Caution! Material damage can result from im-
proper use and operation of the construction!
• Follow they instructions for use to prevent material damage!
• Use the construction for sun protection only!
• Do not use the construction in case of rain or frost!
• Do not use the construction in strong winds (see wind resistance class)!
• Observe the wind resistance class of the construction in order top prevent
the damage to the awning caused by wind!
• Adjust the automatic system control to manual operation in your absence
to prevent automatic operation of the construction. The automatic system
control may fail under extreme conditions e.g. power failures, defects or
sudden storms (danger that the awning could be damaged or fall down).
• If there is a risk of frost, rain or storm, the awning system must be switched
from automatic to manual control to prevent it from moving automatically
• Retract the awning in case of frost, rain or portending storm.
• Follow the cleaning instructions in order to prevent damage to the con-
struction due to erroneous or incomplete cleaning or due tio improper
cleaning agents.
• Adhere to the maintenance instructions/maintenance intervals.
• Only use spare parts which have been approved by the manufacturer!
Danger level III
Danger level
II
Danger level
I
