Attention! For your own safety, disconnect the positive battery terminal
(+12V) or remove the main fuse of the 12V power cable, before you start
any wiring work!
Once the location where the amplifier will be mounted is found, use the unit as a
template and mark the mounting holes with pencil or felt-tip marker. Pilot-drill the
these holes, using a 2,5mm or 3mm drill bit on your power drill. Insert the supplied
rubber washers into the mounting holes of the amp. The amplifier must be mounted
totally isolated from the vehicle's chassis ground, or metal parts. Now bolt the unit
in place with the supplied self tapping screws.

CABLE ROUTING

RCA INTERCONNECTS AND REMOTE WIRING

Run the RCA interconnects and the remote lead from the head-unit to the amplifier.
Note that RCA interconnects must be routed separately from the main +12V power
cable. Connect the remote (turn on/turn off) lead to the REM input terminal of the
amplifier and to the remote output lead of your head-unit. Now plug in the RCA
interconnects to the line-outs of the head-unit and to the RCA inputs of the amplifier.
Pay attention when connecting the RCA cables: The left line out must be connected
to L-CH input, the right line out must be connected to R-CH input.
LOUDSPEAKER WIRE ROUTING
Once the speaker cables have been routed, turn loose the speaker terminal screws
and after inserting the stripped speaker cables, tighten up the screws. Always
maintain correct electrical polarity of speaker wires to the respective terminal („+"
to „+"; „-" to „-").

MAIN POWER CABLES

Run the positive main power cable („+12 V") directly from the positive terminal of the
car battery to the amplifier. For protection of your car audio system against electrical
short cuts and fire hazards, you must insert a fuse holder within the first 30cm of the
positive main power cable. The amperage rating of the fuse must match with the
limitations of your main power cable cross section and serves to protect the vehicle
from a shortcut of the +12V cable to chassis ground!
Connect the ground cable to the ground terminal input of your amplifier and the
other side of the cable to a rust free ground point in your vehicle. Keep the ground
cable („-12V") as short as possible. The ground power cable must have the same
cross-section as the positive power cable.
Tighten up both power input terminals, and double check for perfect and solid fit!
