1
MAIN LEVEL ADJUST
Preset of the main level of the system - subwoofer will be adjusted too, corresponding the preset of the SUB
LEVEL.
2
SUB PHASE
Phase invertation switch to invert the Phase of the Subwoofer (0° / 180°) if necessary due to an difficult
installation.
3
SUB LEVEL ADJUST
Preset subwoofer level proportionally to the satellite level. We recommend at the standard setting 12:00
o'clock level.
4
PROTECT LED
Flashes RED if device switches to protect mode: Check cable for shortening or incorrect connection.
If protect mode continues please contact authorized personel for servicing.
5
INPUT RCA (LEFT / RIGHT)
Asymmetrical Line Input for RCA jack.
6
INPUT XLR / 3.6 mm jack (LEFT / RIGHT)
Symetrical Line Input for XLR connectors and 6.3 mm jacks.
7
LINE DIRECT OUTPUT (LEFT / RIGHT)
Direct symetrical Line Input for XLR connectors.
8
SPEAKER OUTPUT (LEFT / RIGHT)
Speakon® compatible speaker output. Minimum impedance speaker 4 ohms. Used pins are: 1+ / 1-.
9
POWER SWITCH
ON / OFF switch. Please switch connected devices to ONfirst and to OFF after switching the system.
10
POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if power
connection is disconnected. If fuse blows repeatedly please contact authorized personel for servicing.
PANEL DAVE12G2 & DAVE15G2:
9
