1 MAIN LEVEL ADJUST
Preset of the main level of the system - subwoofer will be adjusted too, corresponding the preset of the SUB
LEVEL.
2 SUB PHASE
Phase invertation switch to invert the Phase of the Subwoofer (0° / 180°) if necessary due to an difficult
installation.
3 SUB LEVEL ADJUST
Preset subwoofer level proportionally to the satellite level. We recommend at the standard setting 12:00
o'clock level.
4 INPUT RCA (LEFT / RIGHT)
Asymmetrical Line Input for RCA jack
5 INPUT XLR (LEFT / RIGHT)
Symetrical Line Input for XLR connectors.
6 SPEAKER OUTPUT (LEFT / RIGHT)
Speakon® compatible speaker output. Minimum impedance speaker 4 ohms. Used pins are: 1+ / 1-.
7 POWER SWITCH
ON / OFF switch. Please switch connected devices to ON first and to OFF after switching the system.
8 POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if power
connection is disconnected. If fuse blows repeatedly please contact authorized personel for servicing.
PANEL DAVE10G2:
