COMMANDS AND FUNCTIONS
AMPLIFIER PANEL (PIC.1)
1) "VOLUME" CONTROL
The knob regulates the diffuser's volume.
This control does not affect the output "LINK" levels.
2) "LIMITER" INDICATOR LIGHT
The "LIMITER" indicator light comes on red during start (for a few seconds) and
when the internal audio limiter engages. This avoids the amplifier's distortion and
protects the loudspeakers against overloads.
3) "POWER" INDICATOR LIGHT
The "POWER" indicator light comes on green to indicate that the amplifier is
switched on and it is working properly.
4) EQUALIZATION CONTROL
This control permits the equalization of the speaker.
The "FLAT" central position permits a linear sound reproduction of the speaker. By
turning the control towards "VOICE", the response curve of the speaker highlights
the mid frequencies while if the control is turned towards "MUSIC", the low and high
frequencies are highlighted.
This control does not affect the level of the output signal (link).
5) "BALANCED INPUTS LINK" CONNECTORS
These balanced inputs can be used to connect audio sources at line level (0dB)
(eg. preamplifier, mixer, recorder, CD player, musical instrument, ...).
The balanced connector is connected in parallel and can be used to send the audio
signal to other amplified speakers, recorders or supplementary amplifiers.
6) POWER SWITCH "POWER"
This switch can be used to switch the diffuser on and off.
7) POWER CABLE SOCKET "MAINS"
Used for connecting the power cable supplied.
8) FUSE CARRIER "FUSE"
Mains fuse housing.
9) VOLTAGE CHANGE "VOLTAGE SELECTOR"
For changing the power voltage of the speaker (240V/120V).
This switch is preset and protected by the manufacturer.
ROTATING HORN
Speakers are always supplied by the manufacturer with the horn driver positioned
horizontal at 90° .
If you wish to change the coverage angle (PIC. 2):
- undo the fixing screws of the grille
- remove the front protective grille by slightly pressing on one side and taking the
grille off the special slots
- undo the eight fixing screws of the horn
- rotate the horn in the desired position (the horn should never be removed from the
loudspeaker)
- tighten the fixing screws of the horn
- put the grille back in the special side slots and tighten the screws of the grille.
7
LOUDSPEAKER INSTALLATION
WARNING
Make sure that the loudspeaker in securely installed in a stable position to avoid any
injuries or damages to persons or property.
For safety reasons do not place one loudspeaker on top of another without proper
fastening systems. Before hanging the loudspeaker check all the components for
damages, deformations, missing or damaged parts that may compromise safety during
installation.
If you use the loudspeakers outdoors avoid places that are exposed to bad weather.
The loudspeaker has the following mounting options:
- floor (monitor) (FIG.3)
- standmount - only for M12-4 PLUS (FIG.4)
- suspended with support rails or brackets supplied by the manufacturer - only for
M12-4 PLUS (FIG.5)

TECHNICAL DATA AND DIMENSIONS

TECHNICAL DATA M10-2 PLUS
System ACTIVE / BI-AMPS
Type of amplifier HIGH - class AB
LOW - class H
RMS Power 150W LF + 50W HF
Musical power 300W LF + 100W HF
Frequency response (-3dB) 70 - 19.000 Hz
Crossover Ft 2000 Hz
DR 12 dB/oct
W 12dB/oct
Sound pressure (SPL) 120 dB max
Components 1 x woofer 10"
voice coil 2"
1 x driver 1"
voice coil 1" exit
Dispersion 90°x70° (rotary)
Input sensitivity 0dB
Impedance input balace 30K
Alimentation
Dimensions (LxHxP) 380x286x493 mm
Weight 13,7 Kg
Flying support ---
Stan standard stirrup ---
M12-4 PLUS
ACTIVE / BI-AMPS
HIGH - class AB
LOWI - class H
250W LF+50W HF
500W LF+100W HF
68 - 19.000 Hz
Ft 2000 Hz
CD 12 dB/oct
W 12dB/oct
126 dB max
1 x woofer 12"
voice coil 2"
1 x compress. Driver 1,4"
voice coil 1" exit
90°x70° (rotary)
0dB
30K
see label on the box
400x387x525 mm
18,4 Kg
10MA x 3 points
D36mm
