Error Diagnosis

Error State
E05 Door neither opens nor closes
E06 Door reverses
E07 Door reverses
E08 Door neither opens nor closes
E09 Door neither opens nor closes
E10 Teaching move for light barrier position
F01 No movement of door / dock leveller
F02 No response
F03 No response
F04 No response
F05 No response
F06 No response
F07 Door neither opens nor closes
F08 Function add-on control defective
F09 No movement of door / dock leveller
F10 Door stops shortly after START
command given
F11 Dock leveller cannot be operated any more
F14 Valve 1 interruption
F17 No response dock leveller
F19 Door responds only to dead man's
control for closing
F20 Door responds only to dead man's
control for closing
F21 Operation briefly interrupted
F22 Operation briefly interrupted
F23 No response to START command
F24 No response to START command
F25 No response
F26 No response
F28 No response to START command
F29
End-of-travel-positions shifted
Motor not running
Motor rotates in the wrong direction
F30 Door responds only to dead man's
control for closing
F31 No response
F32 Door neither opens nor closes
F33 Door stopped while opening
F34 Door neither opens nor closes
F35 Door neither opens nor closes
F40 Expansion control
F41 Expansion control
Diagnosis / Remedy
The slack cable switch has tripped (see Fig. 8c).
Closing edge has been triggered.
Photocell has been triggered. Check menu setting [36]
External safety device (emergency-STOP, slack cable, wicket door, motor's thermal
switch) has been activated. Check (J4).
No end-of-travel positions learned. Programme the end-of-travel positions [30] [31].
Allow door to open and close fully in order for the position of the photocell to be detected.
Wrong mains voltage, check rotary field, change rotation.
Error occurred during self-testing
Error occurred during self-testing
Error occurred during self-testing
Error occurred during self-testing
Safety edges defective, Check voltage (J3.3 - J3.1 >12V).
The 24V power supply has broken down. Check the connections.
Fault in the add-on controls. Check the add-on controls.
Overcurrent detector at hydraulic motor. Check mains. Inspect hydraulic motor.
Door neither opens nor closes . Malfunction in the control unit electronics.
Replace control unit .
Fault in the relays for valve 1. Valve current too high. Check valve to identify short circuit.
Valve 1, check feeding line.
Fault in the hydraulic motor.
Closing edge self-testing has failed. Check safety edge.
Photocell self-testing has failed. Check photocell.
Door operator's excess travel stop activated, allow operator to cool down for approx. 20 min.
Hydraulic motor's excess travel stop activated, allow hydraulic motor to cool down for
approx. 20 min.
Door's end-of-travel positions defective. Check end-of-travel positions and if necessary re-
adjust.
No connection to DES. Check motor connecting lead and DES.
Internal testing of membrane keypad defective. Replace membrane keypad.
Internal testing of external buttons / switches has failed.
Fault in the voltage supply. Check mains connection.
Plausibility error of DES.
Check mechanics of both motor and door.
Check both motor and motor connecting lead.
Mains phases have been exchanged; correct or reset.
Returns from impulse to dead man's control.
Check safety edges and photocell.
Button pressed when mains was switched on. Press mains isolator again.
Inspect safety wheel chock .
Spring breakage detection has been activated. Check springs and if necessary replace and
programme the end-of-travel positions again.
Opening force limit activated. Thereafter, the door can only be closed via the dead man's
control. Eliminate sluggishness or blocking of door. Check springs. Eliminate the reason
for the excessive force being applied, so that the door can be opened and closed again.
The ON period has been exceeded. Wait and let the motor cool down.
The speed monitoring has tripped. Exchange DU drive.
The 24-V power supply has broken down. Check the connections at the expansion control.
Fault during the self-test. Replace the expansion control.
Check menu setting [35].
.
, exchange control unit.
, exchange control unit.
, exchange control unit.
, exchange control unit.
