General Information

Setting up the
Controller
16
Your PYROTEC PY1 uses the latest technology
available concerning firing safety, accuracy and easy
handling. Appearing as a handy controller easy to use, it
is a highly sophisticated instrument with a totally
configurable control design allowing adaption to almost
all applications. Reading through this manual quickly
familiarizes you with the numerous features of your
PYROTEC PY1.
Please also refer to the safety advice of your kiln
manufacturer. Make sure that the control is placed at a
proper distance from the kiln and is not exposed to direct
heat or radiation from the kiln.
Depending on the kiln model the controller is either
mounted on the kilns operating panel or on the wall (use
mounting bracket coming with the kiln).
Note: Never place the PYROTEC PY1
controller on the top of your kiln!
Your PYROTEC kiln and controller has passed extended
tests during the manufacturing process. However, we
strongly recommend never to fire the kiln unattended
especially at the end of the firing.
Attach the PYROTEC PY1 controller on the kilns resp.
the wall bracket. The controller is connected to the kiln
by a multipole plug (fits only in one orientation). After
plugging in, secure the plug with the clip.
When turning on the controller with the power switch (11)
after 3 seconds display (1) shows the actual kiln
temperature. Your PYROTEC PY1 is now ready for use.
