GXL 12
Installation and Operating
Instructions
LEAVE THIS INSTRUCTION LEAFLET WITH THE
FAN, FOR THE BENEFIT OF THE USER.
INSTALLING THE FAN
These appliances are intended for connection to fixed wiring. Check
that the electrical rating shown on the fan matches the mains supply.
All installations must be supervised by a qualified electrician.
Installations and wiring must conform to current IEE Regulations (UK).
Local or appropriate regulations (other countries).
WARNING: THESE APPLIANCES MUST BE EARTHED.
It is the installer's responsibility to ensure that the appropriate Building
codes of Practice are adhered to. This appliance is not intended for
use by persons (including children and the infirm) with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their
safety.
Children should be supervised to ensure that they do not play with the
appliance.
1
Description
GXL 12 fans have the following features:
Window, wall, panel or roof mounted.
Are fitted with silent operation back draft shutters.
The GXL 12 can be extract, intake or "open shutter only", using an integral Fan
Selector Switch.
Trickle Ventilation setting.
Can be installed with a controller.
If used with a speed controller, the GXL 12 can intake or extract at
selected speeds or at variable speed depending on the type of
controller, if used with an on/off switch, the GXL 12 will intake or extract
at high speed.
2
What the installer will need
If installing the fan with an on/off switch.
3 core cable
A means for disconnection in all poles must be incorporated in the fixed
wiring in accordance with the wiring regulations.
6mm Blade Large Screwdriver, 3mm Blade Electricians Screwdriver, No's 1
& 2 Pozidriv Screwdrivers.
If wall mounting the fan, you will also need:
Mortar (to make good the hole).
Wall Kit GXL WK 12 or a tube 315mm
internal diameter.
If window mounting the fan, you will also need:
A single glazed non-operating window with a minimum glass thickness of
4mm.
If roof mounting the fan, you will also need.
Roof cowl
Roof mounting plate for flat roof installation.
If installing the fan with a controller
5 core cable. Note. Please check the instructions fro the controller.
3
Where to locate the Fan
Locate it as high as possible.
At least 250mm from the edges of the wall or Window frame to the centre
of the hole.
As far away as possible from and opposite to the main source of air
replacement to ensure airflow across the room(e.g. opposite the internal
doorway).
Near the source of steam or odours.
o
Not where ambient temperatures are likely to exceed 50
C.
When the fan is installed in a room containing a fuel burning
appliance, precautions must be taken to avoid the backflow of gases
into the room from the open flue of the fuel burning appliance.
If the fan is intended to intake air, the inlet grille should be
sited at a distance of at least 0.5metre from the discharge
outlet of a flued heating or cooking appliance.
When intended for use in possible chemical corrosive atmospheres,
you must consult our Technical Service Department.
This product must not be installed in zone 0.
4
Installing the isolating Switch and Cables
1. Check there are no buried Pipes or Cables e.g. Electricity, Gas, Water
behind the Switch location (in the Wall or above the Ceiling).
2. Lay in the Cable from the Isolating Switch to the Fan location.
3. Lay in the Cable from the Isolating Switch to the point of connection to the
Mains Supply.
4. Install the Isolating Switch.
5. Make all connections within the Isolating Switch.
WARNING: Do not make any connections to the Electrical Supply
at this stage.
(Continued)
5. Make all connections within the Isolating Switch.
WARNING: Do not make any connections to the Electrical Supply at this
stage.
For Australia only: These models are permanently connected to the supply and
operation is controlled by a remote switch. They should be directly wired to the
supply through an approved 10A wall mounted surface switch with at least 3mm
clearance between contracts.
Preparing the hole
If installing in a window, get a ready-cut pane to the dimensions given in Fig. 1.
If installing in a wall:
1. Make sure that the centre of the hole is located at least 250mm from the edges
of the wall.
2. Check there are no buried pipes of cables in the wall or obstructions on
the outside e.g. Electricity, Gas, Water.
3. Mark on the wall the centre of the hole and drill right through.
4. Draw a circle on this centre to suit the wall duct.
5. Cut the hole. Do not cut right through the wall.
(The recommended method is to drill a series of holes, close together, around the
edge of the cutting line and remove the brick between the holes with a chisel.
Warning: eye protection must be worn).
6. Go outside and cut a hole in the outer wall, repeating the process described
above.
7. Fit the ducting.
8. Make good the hole. Allow the Mortar to set before continuing the Fan
installation.
Separate the Fan from the Inner Clamp Plate
1. Remove the inner grill and back draught shutter by first removing the screw
from the underside of the grille then unclipping the bottom of the grille, the top of
the grille can then be released by unclipping the top corner. The shutter can then
be unclipped. NOTE: The top of the grille can only be released when the screw is
removed and the bottom of the grille has been released (Fig. 2).
2. Unscrew the four cross-headed screws and lift off the Fan (Fig. 3).
Mount the Fan in the hole (Fig. 4)
recommended that the instructions of this section are carried out by two
people.
If working above Ground Floor level, appropriate safety precautions must be
observed.
If installing the fan in a window, fix the three rubber edge protectors (packed
separately) at equal distances around the lip of the Outer Clamp Plate.
1. Attach the Ladder Strips (packed separately) to the Outer Clamp Plate.
2. Hold the Outer Grille up to the outside of the wall or window so that the lip of
the Outer Clamp Plate protrudes into the hole.
3. Hold the Inner Clamp Plate to the inside of the wall or window and guide the
Ladder Strips from the Outer Clamp Plate through the slots in the Inner Clamp
Plate.
4. Insert the slotted screws (packed separately) into the pockets around the
ladder Strip slots.
5. Tighten the screws carefully to make a good seal.
Do not overtighten.
6. Trim the Ladder Strips back to the required length, if necessary remove any
sharp edges.
Refit the Fan to the Inner Clamp Plate
1. Fit the Fan Assembly onto the Inner Clamp Plate (Fig. 3).
2. Make sure that the Ladder Strips go inside the Fan Assembly so they will not
get caught in the blades.
3. Tighten up the four screws. Do not overtighten.
Wire the electrical connections
1. Remove the Fan Connector Plate carefully by unscrewing the two screws (Fig.
5). The Connector Assembly parts are contained loosely behind this plate.
2. Remove the two cable clamp screws (Fig. 8a and 8b).
3. If required, feed the cable through the grommet (packed separately) in order to
fit to the cable entry of the Connector Plate.
If installing a GXL 12 with an on/off switch:
1. Wire the Fan Connector as shown in Fig. 6.
2. Set the Fan Selector Switch to Position 1 for intake, Position 2 for extract or
Position 3 for "open shutter only" (Fig. 7).
If installing a GXL 12 with a controller:
1. Refer to the installation instructions for the controller.
2. If wiring to an existing controller, contact Technical Services
3. Set the Fan Selector Switch to Position 3 if using a controller providing variable
speed and/or direction. Otherwise, set the Fan Selector Switch to Position 1 for
intake, Position 2 for extract or Position 3 for "open shutter only" (Fig. 7).
Fitting the Cable Clamp
For the GXL 12 :
For cable up to 8mm diameter, clamp the cable as shown in Fig. 8a.
For cable equal to or greater than 8mm and up to 11.5mm diameter, clamp the
cable shown in Fig. 8b.
For cable greater than 11.5mm diameter use the conduit entry provided.
Fitting the Connector to the Fan
1. Ensure the cable is firmly retained by the clamp.
2. Assemble the Fan Connector by snapping the Cover over the
Connector (Fig. 9).
3. Plug the Fan Connector into the Fan Assembly.
4. Refit the Connector Plate (Fig. 5).
5. Refit the Backdraft Shutter.
6. Refit the Inner Grille.
7. Switch off the mains electrical supply and remove fuses.
8. Connect the cable from the isolation switch to the electrical supply writing.
9. Replace the fuses, and switch on the mains electrical supply.
For fixed wiring circuits the protective fuse for the appliance must not
exceed 5A.
USING YOUR FAN
Operating the Fan
GXL 12 (switch operated):
To switch on and off, use the switch on the wall or ceiling.
GXL 12 (controller operated):
Refer to the instructions for the controller.
The shutters are operated by a silent thermo-actuator which has a time delay
on opening (30-50 secs) and closing (3 mins).
Trickle Ventilation
Trickle Ventilation is equivalent to that provided by an air brick or similar
device.
1. Remove the inner grill and back draught shutter by first removing the screw
from the underside of the grille then unclipping the bottom of the grille, the top of
the grille can then be released by unclipping the top corner. The shutter can then
be unclipped. NOTE: The top of the grille can only be released when the screw is
removed and the bottom of the grille has been released (Fig. 2).
To allow trickle ventilation:
2. Release the Shutter Return Spring as shown in Fig. 10.
3. Re-position the Shutter Return Spring into the L-shaped slot.
4. Raise the Operating Bar to latch into position.
To fully close the shutters and stop any backdraught:
5. Unlatch the Shutter Return Spring and re-position into the short slot.
6. Refit the Back Draught Shutter and Inner Grille.
LOOKING AFTER YOUR FAN
Cleaning
1. Before cleaning, isolate the fan from the mains supply. Allow 3 minutes for the
impeller to stop rotating and the powered shutter to close.
2. Remove the inner grill and back draught shutter by first removing the screw
from the underside of the grille then unclipping the bottom of the grille, the top of
the grille can then be released by unclipping the top corner. The shutter can then
be unclipped. NOTE: The top of the grille can only be released when the screw is
removed and the bottom of the grille has been released (Fig. 2). WARNING: The
fan will still operate when the inner grille is removed.
3. Remove the impeller by unscrewing the knob at the front of the impeller.
anticlockwise.
4. Clean the inner grille, back-draught shutter and impeller by immersing in warm
soapy water. Dry thoroughly.
Do not immerse the fan in water or other liquids to clean any other parts of the
fan.
5. Refit the impeller by locating it over the motor shaft and aligning the arrow on
the impeller with the white dot on the motor. Make sure the impeller is seated
correctly.
6. Refit the knob making sure the ratchet at the rear of the knob is fully engaged.
Never use strong solvents to clean the fan.
Apart from cleaning, no other maintenance is required.
KEY (For Fig. 11)
Inner Grille.........................................."A"
Ladder Strips.................................."F"
Back Draught Shutter........................."B"
Connector Plate .............................."G"
Fan Assembly ....................................."C"
Rating Plate ...................................."H"
Inner Clamp Plate..............................."D"
Selector Switch .......................... . ."J"
Outer Clamp Plate/Grille....................."E"
7
Werbung
