User manual / Bedienungsanleitung
2.5.5. Adjustment of the Tracking force
By loosen the screw on the counterweight on the tonearm-tube you ou can adjust the tracking force
of your cartridge by moving the counterweight (shown in the picture below).
Pic. 12: Adjustment of the tracking force
2.5.6 Adjustment of the Anti-Skating
You will find the Anti – skating adjustment wheel on the bottom of the tonearm (Pic. 13).
The factory installation is preset for a clearaudio MM cartridge at tracking force 2.4 grams and
marked with a black stripe on the bolt (view bottom up).
You can change your Anti-Skating:
Clockwise (max. 5 turns)= more Anti - Skating
Counter – clockwise (max. 5 turns) = less Anti - Skating
The general set-up is now finished.
Pic. 13: Adjustment of the Anti-Skating
Now you can connect your Verify tonearm now with the phono input of your phono-preamplifier.
Attention:
Before the first use or after a long storage, please apply the lift unit up and down
approximately 4-5 times, so that the oil inside can dissolve in order that the lift unit can
move smoothly.
8
red arrow (to the end of the tonearm)
= lesser tracking force
green arrow (to the beginning of the
tonearm)
= more tracking force
With 4 turns = Tracking force is 2.2 grams
With 3 turn = Tracking force is 2.4 gram
For a perfect Anti-Skating we recommend the
Clearaudio Test record (LPT43039) available at
www.analogshop.de or contact your nearest dealer
or distributor.
