2. CONNECTIONS & CONTROLS
2.1 FRONT PANEL CONNECT�ONS �� CONTROLS ANEL CONNECT�ONS �� CONTROLS
01 POWER LED
Green "operation" LED, signaling correct operation of the amplifier
02 INPUT GAIN CONTROL
�nput level gain control potentiometer, allowing to match the output voltage of the headunit's
RCA line-outs to the amplifier input section
03 RCA INPUTS 1/2-CH
Low-level stereo RCA signal input for connection with line-out of the head-unit (sub-out)
04 SUBSONIC CROSSOVER FREQUENCY CONTROL
Crossover control potentiometer for the frequency adjustment of the 24 dB/oct. subsonic
high-pass filter
05 LOW PASS CROSSOVER FREQUENCY CONTROL
Crossover control potentiometer for the frequency adjustment of the 24dB/oct. low-pass
filter
06 PHASE SHIFT CONTROL
Phase control potentiometer for the relative phase adjustment of the subwoofer(s) connected
to the amplifier output terminals
07 RCA FOR MASTER/SLAVE OPERATION
RCA input/output to connect another
operation
8 SWITCH FOR MASTER/SLAVE OPERATION
Slide switch to define each amp being either master or slave
9 REMOTE LOW PASS LEVEL PORT
Telephone jack input socket for connection with the dash-mounted lowpass level remote
unit
10 PROTECTION LED
Red "protection" LED, signaling faulty speaker connections or general malfunction of the
amplifier

class-D amplifier, for master/slave
EA15000SPL
