reset.
NoTE:
The transmitters are memorised on an EPROM memory (U2), which can be extracted from the control unit
and inserted in a new CORE control unit should a replacement is required.
For safety reasons, the transmitters can be stored in memory during the opening/closing of the motor.
If the transmitter code is already stored in the receiver, the remote radio learning can be carried out
(without accessing the control unit).
ImPoRTANT: The procedure should be carried out with gate in the opening phase, during the TCA
dwell time.
Proceed as follows:
1 Press the hidden key of the transmitter, the code of which has already been stored in memory.
2 Within 5 seconds, press the already memorised transmitter key corresponding to the channel to be
matched to the new transmitter. The flashing light switches on.
3 Within 10 seconds, press the hidden key of the new transmitter.
4 Within 5 seconds, press the key of the new transmitter to be matched to the channel selected at item 2.
The flashing light switches off.
5 The receiver stores the new transmitter code and exits from the programming mode immediately.
The red LED DL1 indicates the activation of inputs according to the legend hereunder:
STOP
PHOT
SWO
SWC
OPEN+CLOSE
By flashing slowly, the red LED DL1 also indicates that the unit is powered.
The green LED DL2 indicates the movement direction of the motor and the status of the gate according
to the legend hereunder:
APERTURA
CHIUSURA
Open gate without TCA
Open gate with TCA
Closed gate
If the product must be dismantled, it must be disposed according to regulations in force regarding the
differentiated waste disposal and the recycling of components (metals, plastics, electric cables, etc..). For
this operation it is advisable to call your installer or a specialised company.
12
TRANSmITTER REmoTE LEARNING
on with fixed light
rapid flashing
1 flash with 2-second interval
2 flashes with 2-second interval
3 flashes with 2-second interval
1 flash with 1-second interval
2 flashes with 1-second interval
on with fixed light
rapid flash
LED off

LED DIAGNoSTICS

WASTE DISPoSAL
