Operating the field indicator
Menu Operating function
Parameter
Operating User code
parameters CODE
PARAM
0000 to 9999
NAMUR
NAMUR
Default
Edit
NAMUR 20.5*
N2050
NAMUR 3.80
to NAMUR
21.0
Service Service code
SERV SCODE
*) only if "Edit" has been selected for NAMUR
**) only if "TEXT" has been selected for DIMENSION
***) only available for service personnel
5.4 Configuration via interface & FieldCare Device Setup PC
configuration software
WARNING
!
Loss of explosion protection when housing is open
‣
The device must be configured outside the hazardous area.
CAUTION
!
Undefined switching of outputs and relays during configuration
‣
While configuring with FieldCare the device may assume undefined states.
To configure the device with the FieldCare Device Setup software, connect the device to your PC.
You need a special interface adapter for this purpose - the Commubox FXA291 (see Chapter
'Accessories').
The 4-pin connector of the interface cable must be plugged into the corresponding socket inside
the device and the USB connector must be plugged into a free USB slot on the PC.
Connection establishment
When connecting the device, the device DTM is not automatically loaded in FieldCare, i.e. the
device has to be added manually.
38
Operating function
Default / Parameter
Choice
Program name
PNAME
0000
NAMUR 3.6*
N_360
dEF 0 to NAMUR
Edit 20.5
NAMUR 21.0*
N2100
20.50 NAMUR 20.5
to 25 mA
Parameter reset***
PRSET
- - - - Yes
No
Operating function
Default / Parameter
Choice
Firmware version
FWVER
NAMUR 3.80*
N_380
3.60 NAMUR 3.6
to NAMUR
20.5
Test
TEST
21.00 off
Open Collect.
Display
Yes
No
RIA14
Default /
Choice
3.80
OFF
OUT
DISP
