ENGLISH
RANGE OF CARTRIDGES
PA 1200 has an individual temperature control
for each cartridge so it is supplied individually.
All the cartridges shown are actual size.
Changing the cartridge
To extract the cartridge the screw needs to
be unfastened and the cartridge pulled out.
I n s e r t t h e n e w c a r t r i d g e a n d p u s h i t
thoroughly. Then check that both tips of the
tweezers coincide and screw it.
Cartridge and
connection screw
WARNING: It is esential to tighten this screw
for the tool to function.
Important.
- It is essential to insert the cartridge till
the end for a good connection. Take the
mark as reference and check that both
parts of the tweezer coincide.
Alignment
JBC reserves the right to make technical changes without prior
notification.
