N°
DESCRIPTION
1
Circlip, dia. 15 mm
2
Front wheel
3
Trolley body
4
Rear wheel
5
Split washer, dia. 10x16 mm
Jack attachment screw, hex head,
6
M10X30 mm
7
Circlip, dia. 20 mm
8
R-clip
Attachment screw, hex head,
9
M8X20
10
Split washer, dia. 8x13 mm
SPARE PARTS LIST
Qty
N°
DESCRIPTION
11
2
Rubber stop
2
12
Lever stop rod
1
13
Lever attachment screw
2
14
Split washer, dia. 18x27 mm
4
15
Split washer, dia. 16x24 mm
16
4
Wheel nut, M16
2
17
Lever socket
3
18
Lever (upper section)
Lever locking screw, hex head,
19
2
M12x10
Lever assembly screw, hex head
2
20
M6X35 mm
39
Qty
N°
DESCRIPTION
21
2
Lever (lower section)
1
22
Hydraulic jack
2
23
Return spring
2
24
Circlip, dia. 15 mm
2
25
Split pin
26
2
Rod head
1
27
Safety pin
1
28
Arm pin
29
1
Tie rod
1
30
Circlip, dia. 22 mm
38
Qty
N°
DESCRIPTION
31
1
Lifting arm
1
32
Rubber pad
2
33
Bearing plate
4
34
Locking pin
1
35
Left-hand front wheel support
36
1
Intermediate adjustment pin
Right-hand front wheel
1
37
support
1
38
Linchpin
2
39
Retaining strap
2
19
Qty
1
1
1
1
1
2
1
1
2
EN
