LED fault display
An LED flashes quickly when switching on the device.
 Battery is empty
 Charge the device.
An LED flashes quickly twice when inserting the charg-
er.
 Device too hot to charge (e.g. after operation in
high ambient temperatures or if filter is clogged).
 Let the device cool down (charger can remain
plugged in), the charging process will automatically
start at the appropriate temperature.
All LEDs flash.
 Battery or electronic fault.
 Take device to Service.

Technical specifications

Appliance type
Nominal battery voltage
Rated power of appliance
Operating time with full
charge
- Min. suction performance
- Max. suction performance
Charging current for empty
battery
Charger initial voltage:
Output current, charger
Battery type
Protective class
Charger
Protective class
Weight (without accesso-
ries)
Device with floor nozzle
Length x width x height
(Device in parking position)
Sound power level L
Subject to technical modifications!
10
V 18
W 125
min 40
min 11
min 180
V 22
A 0,6
Li-ion
III
II
kg 2,8
mm 182x26
1x621
dB(A) 69,4
WA
25,2
190
60
15
180
30
0,6
Li-ion
III
II
2,9
182x261x
621
75,5
– 7
EN
