3 - OPERATING INSTRUCTIONS
1.3 - INFRARED REMOTE CONTROL
DEVICE
The remote control device needs two
non-rechargeable batteries (1,5 V).
1.4 - INTRODUCTION OF THE BATTER-
IES:
Open the gain door. Remove the cover of
the batteries gain on the backside of the
remote control device pressing the
tongue inside according to the arrow
direction.
The longest operational distance of the
remote control device is about 5 mt.
There must not be any obstacles
between the remote control device and
the unit.
To send out controls to the unit it is nec-
essary to point the remote control device
towards the VEGA MK II control panel
and press the button corresponding to the
chosen function.
1.5 - OPERATING INSTRUCTIONS
DIGITAL CONTROL PANEL VEGA MK II
REMOTE CONTROL DEVICE
(only with the digital panel VEGA MK II)
Buttons functions:
Button n.1:
It increases the Temperature Set Point
value.
Button n.2:
It changes the luminosity of the warning
lights and of the display on a four level
scale.
Button n.3:
It decreases theTemperature Set Point
value.
Button n.4:
Fan speed control. Four manual speeds
(1 - 2 - 3 - 4) or automatic speeds.
Button n.5:
Special modes:Unattended, Dehumidify
or Fan Only.
Button n.6:
ON/OFF button.
When the panel is ON, the display
shows the ambient temperature (or the
abbreviations U,
Unattended, Dehumidify or Fan Only
Modes are set up) + mode and fan warn-
ing lights.
When the panel is OFF, the display
shows only the ambient temperature
and all the warning lights are switched
off.
Button n.7:
Automatic speed selection (A).
The remote control device needs two non-
rechargeable batteries (1,5 V).
