7.5 Setting the channel, ID, and group

The Walimex pro Operator TTL T-C transmitter has 8 channels and 30 radio IDs.
Using the same channel, the Walimex pro Operator TTL T-C allows you to se-
parately control flashes in three groups simultaneously or independently. Each
Set Channel 、ID and Group
Set Channel 、ID and Group
group can have as many lights as needed. This is ideal for working with multiple
lighting setups. You can work with remote lights, maintaining total control and
without leaving your position.
Setting the channel of the radio transmitter
1. The radio transmitter offers 8 channels, selectable from CH 1 to CH 8.
2. P ress and hold the [SYNC/CH] button; only CH shows on the screen. Rotate
the dial to set the correct channel value. Press [OK] to save the value.
Setting the ID of the radio transmitter
1. The radio transmitter offers 30 radio IDs, selectable
from 1 to 30.
2. P ress and hold the [SYNC/CH] button; CH shows
on the screen. Then, briefly press [SYNC/CH]; the
ID code shows on the screen. Rotate the dial to set
the correct ID. Press [OK] to save the value.
Setting the group of the radio transmitter
Press the [GROUP] button to choose and set up the A /B /C group in sequence.
45
、ID
、ID
NOTICE
The Walimex pro Mover 400 TTL studio flash and the flashes of the Walimex
pro VC Excellence series, VC Excellence Plus series, VE Excellence series
and Newcomer series include a built-in radio receiver. They are compatible
with the Walimex pro Operator TTL T-C transmitter. Group, channel, and ID
must be the same as on the transmitter. To set the flashes, please refer to
the user instructions.

7.6 Setting operating modes Gr, ETTL, Multi

Press and hold the [MODE] button for 3 s on the radio transmitter, and switch the
<Gr>/<TTL>/<Multi> modes in sequence.
7.7 Gr Mode: Shooting with a different flash mode for each group
In Gr mode, you can set different flash modes for the A/B/C groups. The selec-
table modes are <TTL>/<M 1/x>/<M>/<OFF>.
Select <Gr> mode: Press and hold the [Mode] button for 3 s, and set the radio
transmitter to <Gr>.
Select flash group: Briefly press the [GROUP] button to select the A, B or C
group. The currently selected group is indicated by a triangle.
Set up flash mode for the selected flash group: Briefly press the [MODE]
button; <TTL>, <M 1/x>, <M> and <OFF> are shown in sequence.
46
