PSI Matrix PP 407 Benutzerhandbuch Seite 209

Barcode Width (Thin bars)
Parameter
Width of the thin bars
P4
for horizontal Barcode
for vertical Barcode
Description
P4 hex
0 30
1 31
2 32
3
33
4 34
5 35
6 36
7
37
P4 hex
0 30
1
31
2 32
3 33
4 34
5
35
6 36
7 37
• default: / = 0.35 mm
2
144
Note: The width of bars and gaps should be equal.
For this, the parameters P4 and P5 should
not deviate more than one step
dec inch
48 2/144
49 3/144
50 4/144
51 5/144
52 6/144
53 7/144
54 8/144
55 9/144
dec inch
48 2/180
49 3/180
50 4/180
51 5/180
52 6/180
53 7/180
54 8/180
55 9/180
Function
mm
0,35
0,53
0,70
0,88
1,05
1,23
1,41
1,58
mm
0,28
0,42
0,56
0,70
0,85
0,99
1,12
1,27
Appendix F-4
