Table 3: Vertical Form Handling
Vertical Form Handling
The printer is always equipped with two continuous form tractors. The last sheet of a continuous
form stack can be printed on up to the end of the form.
The capabillity of the printer to feed paper from different sources is optimally supplemented by the
option that automatically adjust the distance between the print head and the print ba
Escape Sequence
ESC 0
ESC 1
ESC 2
ESC 4
ESC 5 P1
ESC A P1
ESC B NUL
ESC B P1 P2 . . . P64 NUL
ESC C P1
ESC C NUL P1
ESC N P1
ESC O
ESC [ \ EOT NUL NUL NUL P1 NUL
ESC ]
Mnemonic Function
Set Line Space to 1 / 8 "
Set Line Space to 7 / 72 "
Start Variable Line Space
Set Top of Form
Carriage Return Function
P1 = 1 or 0/1: select CR + LF P1 = 0 or 0/0:
cancel CR
Set Line Space
P1 = P1 / 72 " lpi (non AGM)
P1 = P1 / 60 " lpi (AGM) (P1 = 0/1...5/5)
Note: Default = 12 / 72 " or 6 lpi
Clear all Vertical Tabs
Set Vertical Tabs (Pn = 0/1...F/F)
Set Form Length in Lines (P1 = 0/1...7/F)
Set Form Length in Inches (P1 = 0/1...1/6)
Set Automatic Perforation Skip
P1: number of lines from bottom of
paper to skip. (P1 = 0/0...F/F)
Cancel Automatic Perforation Skip
Set Line Space Unit
EOT = 0/4 P1 = B/4 : select 1/180"
P1 = D/8 : select 1/216" P1 = 0/0 : setting
remains unchanged
Reverse Line Feed
