Radiator Bleeders
Technical Data
Operating temperature: max. 100 °C
Introduction
Operating pressure
at the radiator:
We congratulate you on the purchase of
Operating medium:
your new device. You have chosen a high
Use
quality product. The instructions for use are
part of the product. They contain important informa-
Remove old valve
tion concerning safety, use and disposal. Before using
the product, please familiarise yourself with the entire
Before swapping the valves, the radiator must be
safety information and instructions for use. Only use
depressurised.
the product as instructed and only for the stated areas
Remove the valve using the open ended spanner
of use. If you pass the product on to anyone else, please
provided. Remaining pressure in the radiator escapes.
ensure that you also pass on all the documentation
Catch escaping water using a suitable container.
with it.
CAUTION! RISK OF SCALDING! The radiator
must be cooled down.
Intended use
Fitting new valve
This fully automated radiator bleeder is intended for
the automatic and continuous bleeding of water bearing
Note: The fully automatic radiator bleed vent is self-
systems such as radiators, pipes, floor heating mani-
sealing, it is not necessary to use hemp or Teflon tape
folds etc. Any other use or modification of the product
to seal it.
shall be considered as improper use and could give
Fit the valves vertically at the highest point of the
rise to considerable dangers. We will not accept liability
radiator, with the valve head facing upwards or
for loss or damage arising from improper use. The
horizontally, and do NOT fit them with the valve
device is intended for private, domestic use only.
head facing downwards.
Caution: Water leaks possible!
Scope of delivery
Fitting and bleeding
2 valves 1/2"
1 open ended spanner (19/22)
The fully automatic radiator bleed vent is screwed
into the radiator, using the open-ended spanner
provided. The automatic bleeding is now activated.
GB
Now open the radiator again. The bleeding oc-
curs automatically.
Note: After the vent has been fitted, the pressure
min. 0.1 bar, max. 8.5 bar
in the heating system must be checked and, if nec-
water without additives
essary, brought back to the target pressure again.
Quick bleed
For quick bleeding, for instance when first fitting,
the valve head can be screwed out 1 - 2 turns by
hand using the knurled screw (works like manual
bleeding).
As soon as water escapes, the valve must be
turned back in tightly by hand.
Attention: Water leak, please catch with a suit-
able container!
Non-return valve
When the valve head is screwed out completely, a
built-in non-return valve prevents water leakage. Only
necessary in the case of maintenance work.
Note: If necessary call a specialist (plumber or heat-
ing contractor). We assume no liability for valves that
are not fitted properly.
Maintenance
The fully automatic radiator bleed vent is maintenance-
free. It is however recommended, that manual bleeding
once a year is carried out to fully check the functioning.
GB
Cleaning
-
Clean the fully automatic radiator bleed vent from
the outside, using a slightly moist cloth.
Disposal
The packaging is made from environmentally
friendly materials, which may be disposed
through your local recycling facilities.
Contact your local authorities for information on how
Warranty repairs can only be carried out if the receipt
to dispose of the product at the end of product life.
is enclosed.
Many thanks for you understanding.
Warranty
With best wishes
ATTENTION! PLEASE KEEP IMPORTANT WARRANTY
Your Olympia Business Systems Vertriebs
DOCUMENTATION!
GmbH
Dear Customer,
We are delighted that you have decided on a quality
Olympia Business Systems Vertriebs Gmbh
product. Should an unexpected technical problem
Zum Kraftwerk 1
arise with your appliance, please note the following
45527 Hattingen
points:
Germany
-
The warranty period for your appliance is
36 months.
-
Please keep the receipt and the original packaging.
– Should a problem arise, please call our hotline first:
00800 100 22 100 (international)
Our expert staff is often able to help over the phone.
service.uk@gsl-servicenet.de
GB
GB
If the fault can not be rectified over the phone, we
would ask you to send the appliance in its original
packaging to the following address:
GSL mbH
Am Weimarer Berg 6
99510 Apolda
Germany
IAN 90254
Manufacturer
OLYMPIA BUSINESS SYSTEMS VERTRIEBS GMBH
Zum Kraftwerk 1
45527 Hattingen
Stand der Informationen · Last Information Update: 03 / 2013
Ident.-No.: 90254032013-AT
