Safety / Before Initial Use
electrical equipment. Such interventions pose
life-threatening danger due to electric shock.
Before assembly, ensure that the available
mains voltage corresponds to the operating
voltage necessary for the light (220–240 V ∼).
If the mains power cable of this device is dam-
aged, it has to be replaced by the manufacturer
or its service department or a similarly qualified
person in order to avoid hazards.
Please only use halogen bulbs of a rating of
max. 400 W (energy class C) or of a lower rating.
Avoid fire and
injury hazards
RISK OF INJURY! During unpacking please
check bulb and lamp glass immediately for dam-
age. Do not assemble the light with defective
bulbs and / or lamp glass. In this case contact
the service centre for replacement.
RISK OF INJURY FROM BURNS! Ensure
that the lamp has been switched off and has
cooled down before touching it, to avoid burns.
Bulbs develop a lot of heat in the area of the lamp
holder. Allow the light to cool down for at least
15 minutes before replacing a defective bulb.
Exchange a damaged lamp glass
immediately.
Replace faulty bulbs with new bulbs immediately.
FIRE HAZARD! Position the light
so that it is at least 1 m away from
1 m
the material to be illuminated. Exces-
sive heat can result in a fire. Therefore please
ensure that there is sufficient ventilation for heat
dissipation.
Do not adjust the light downwards.
Never look directly into the light. This could
result in damage to your eyes.
Never use the light without lamp glass or metal
covers. Otherwise there is a risk of injury.
Replace the broken protective shields immediately.
6 GB/IE/CY

Before Initial Use

Mounting
Note: The tripod is delivered assembled.
6
Now press the spring pin
same time swivel the tripod
Release the spring pin
groove (see Fig. A).
Turn the twist lock
8
Now adjust the tripod
by sliding the pipe up to the required height.
Turn the twist lock
8
of the tripod (see Fig. B).
6
Undo the middle screw head
Position the middle hole of the halogen light
holder over the top of the stand.
Reposition the middle screw head
top of the stand and tighten it.
Loosen the screws on both ends of the halogen
lamp holder and adjust it to the desired lighting
angle of the light.
Retighten the screws on both ends of the halo-
gen light holder.
Check that the halogen light is fitted safely and
that the tripod stands soundly.
6
Please ensure that the cable does not get stuck
on sharp objects and that the plug is sufficiently
protected from rain and moisture.
Fitting the bulb
Loosen the set screw
ing , which holds the hinged front lid
3
place.
Swing the front lid
Carefully bring the bulb
between the two spring loaded fittings
Ensure that the bulb
holder.
ATTENTION! When inserting the bulb
careful not to touch the glass of the bulb
you accidentally touch the bulb
with a lint free cloth and a bit of denatured
alcohol, before you fit it.
Lift the hinged front lid
upwards and at the
10
feet downwards.
6
. This is fixed in a
10
anti-clockwise (see Fig. B).
to the required height
6
clockwise to fix the height
.
9
on the
9
of the flood light hous-
1
2
downwards.
2
into its position
4
.
5
is seated firmly in the
4
4
4
, clean it
4
up.
2
in
, be
. If
