MAINTENANCE AND VEHICLE
CARE
• Do not disassemble or try to repair the vehicle on
your own. Contact an authorised Peg Perego
customer support centre.
• The toy should not be left anywhere with a
temperature below 0°C. If it were to be used
without being warmed up to a temperature above
0°C, irreversible damage could be caused to the
motors and batteries.
• Check the condition of the vehicle regularly, paying
particular attention to the electrical system, the
plug connections, the terminal protectors and the
battery charger. If defects are identified, the
electrical vehicle and the battery charger must not
be used.
• Always disconnect the battery charger from the
toy before carrying out cleaning, maintenance, or
any type of intervention.
• For repairs use only original PEG PEREGO spare
parts.
• PEG PEREGO do not accept any responsibility for
cases of tampering with the electrical system.
• Do not leave the batteries or the vehicle close to
sources of heat like radiators, fireplaces, etc.
• Protect the vehicle from water, rain, snow, etc.
Using the vehicle on sand or mud may damage the
buttons, motors and gears.
• Lubricate moving parts like bearings, steering, etc.
periodically with light oil.
• The vehicle surfaces can be cleaned with a damp
cloth and, if necessary, with non-abrasive domestic
cleaning products.
• Cleaning must only be carried out by adults.
• Never dismantle the vehicle mechanisms or
motors, unless authorized by PEG PEREGO.
RULES FOR SAFE DRIVING
For the safety of the child, before starting up the
vehicle read and carefully follow the following
instructions.
• Teach the child how to use the vehicle properly for
safe and enjoyable driving.
• The toy must be used with caution, as it requires
substantial dexterity in order to avoid falls or
collisions which could cause injuries to the user or
third parties.
• Before starting, check that there are no people or
objects obstructing the vehicle's path.
• Drive with hands on the handlebars/steering wheel
and always watch the road ahead.
• Brake in good time to avoid collisions.
ATTENTION! The item is equipped with a brake
system which needs to be appropriately illustrated to
the child by an adult.
2nd GEAR (if present)
Initially, use in 1st gear is recommended. Before
enabling 2nd gear, check that the child has learned to
use the handlebars/steering wheel, 1st gear and the
brake correctly, and has become familiar with the
vehicle.
WARNING!
• Check that all the wheel fixing studs/nuts are
fastened properly.
• If the vehicle is overloaded, as can happen on soft
sand, mud, or very uneven ground, the overload
switch will immediately disconnect the power. The
power supply will be restored after a few seconds.
UNINTERRUPTED FUN: Keep a spare set of charged
batteries ready for use.
PROBLEMS?
THE VEHICLE DOES NOT WORK?
• Check that there are no disconnected cables under
the accelerator plate.
• Check the operation of the accelerator button and
replace it if necessary.
• Check that the battery is connected to the
electrical system.
THE VEHICLE LACKS POWER?
• Charge the batteries. If after charging the problem
persists, have the battery and charger checked by
an assistance centre.

CUSTOMER SERVICE

PEG PEREGO offers an after-sales customer
service, directly or through a network of
authorized assistance centres, for any repairs or
replacements and the sale of original spare parts.
To contact a service center, visit our website:
http://global.pegperego.com/toys-
site/support/
The item's serial number must always be quoted.
See the page on spare parts to find out how to
identify the serial number.
ASSEMBLY INSTRUCTIONS
WARNING
ASSEMBLY MUST ONLY BE CARRIED OUT BY
ADULTS. TAKE CARE WHEN REMOVING THE
VEHICLE FROM ITS PACKAGING. ALL THE
SCREWS AND SMALL PARTS ARE CONTAINED IN
A BAG INSIDE THE PACKAGING. THE BATTERY
MAY ALREADY BE FITTED INSIDE THE ITEM.
Do not use the toy if you find it damaged after
opening the packaging. Contact the shop where you
bought it or the customer support centre.
Take care in the presence of children while
assembling the toy, given the risks caused by small
parts (ingestion hazard) and the plastic bags that
contain them (choking hazard).
To assemble the toy, you will need a flat-head
screwdriver, a Phillips screwdriver, a hammer, and a
pair of pliers.
ASSEMBLY
1 • Turn the rear bodywork upside down and attach
the 2 side inserts (DX: right, SX: left), as shown
in the figure.
2 • Attach the inserts using the screws provided.
3 • Insert the 2 tubes with springs into their slots,
keeping the springs pressed down until they are
fully hooked in.
4 • Snap the rear bodywork in place, taking care that
the 8 hooks and 2 front tubes are fully inserted.
5 • Place the vehicle on its side and secure the
bodywork using the 4 screws provided (2 for
each side), as shown in the figure.
6 • Remove the protection caps from the rear axle
and insert it into the engine unit, as shown in the
figure.
7 • Attach the 2 rims to the 2 wider wheels, paying
attention to the direction of the tread, as shown
in the figure.
8 • Install the cross-shaped drivers inside the rear
wheels and then position the wheels on the
engine unit, as shown in the figure.
9 • Insert 1 small washer and 1 nut in each wheel in
this order. Secure the wheels by tightening the
nuts at the same time using the 2 spanners
provided.
10 • Prepare the remaining front wheels, by attaching
the wheel rims (again, paying attention to the
direction of the tread) and positioning the 2
remaining drivers inside them.
11 • Remove the steering lever protection caps. Insert
the following from both sides: one large washer,
the wheel with external rim, 1 small washer, and
the nut, in this order. Tighten the wheels using
the spanner provided and press the 4 hubcaps in
place.
12 • Press the rear roll bar in place.
13 • Apply the decals to the bonnet, following the
instructions. Insert the front windscreen and
fasten it using the 2 screws provided.
14 • Press the wing mirrors in place and tighten them
using the screws provided.
15 • Apply the silver decal to the inside of the
mirrors and fix them to the vehicle using the 2
screws.
16 • Apply the silver decals to the bases of the
headlights and the indicators.
17 • Snap the headlights' and indicators' glass covers
in place.
18 • Press the two parts of the steering wheel (the
steering wheel and under steering wheel ring
nut) together.
19 • Assembling the horn: 1- insert the spring; 2-
remove the plastic tab from the sound module.
The sound module is provided with 3 LR44
batteries and is ready for use. 3- insert the sound
module with the perforated side facing
downwards.
20 • Attach the cap and the frame to the centre of
the steering wheel.
21 • Fasten the steering wheel to the vehicle, using
the nut and screw provided.
22 • Connect the plugs of the battery and the wiring
unit together.
23 • Position the seat by inserting the rear hook into
the chassis and then fastening it by rotating the
front safety hook.
24 • In detail A, the seat is free, in detail B, the seat is
locked in place.
25 • Screw the 2 seatbelts to the vehicle, ensuring
that the writing is the right way around. Apply
the remaining decals. The vehicle is ready for use.
26 • Take the radio control out of its packaging. Use a
screwdriver to remove the screw on the back of
the radio control and open the battery
compartment.
27 • Insert two 1.5 V AA batteries (not Included) into
the battery housing, taking care to match the
correct polarity. When the batteries are in place,
close the battery compartment cover and tighten
the screw.
28 • The dashboard is equipped with:
- A - ignition button: press the button and wait
for the ignition sequence until the Bluetooth
symbol appears on the dashboard. The vehicle is
now ready to be used with the radio control.
- B - direction indicators
- C - overload indicator
- D - emergency light button
- E - vehicle status indicator
- F - battery level indicator
RADIO CONTROL DRIVE MODE
WARNING: THE RADIO CONTROL MUST BE
USED BY ADULTS ONLY.
WARNING: THE RADIO CONTROL IS NOT A
TOY. KEEP IT OUT OF THE REACH OF
CHILDREN!
WARNING: THE RADIO CONTROL MUST
NOT, UNDER ANY CIRCUMSTANCE, BE
CONSIDERED A SAFETY DEVICE AND CANNOT
IN ANY WAY REPLACE THE SUPERVISION OF AN
ADULT AND THE NEED TO BE CLOSE TO THE
TOY IN CASE OF DANGER.
29 • RADIO CONTROL ON: Move the door on the
back of the radio control to access the switch.
Set the switch to ON.
• The radio control drive mode is active when the
vehicle beeps twice successively and the red LED
of the radio control is steady.
30 • USING THE RADIO CONTROL:
• By pulling the trigger in the direction indicated
by the arrow (A), the vehicle will move forwards;
• By pulling the trigger in the opposite direction
(R), the vehicle will move backwards;
31 • By turning the cursor to the right or left, the
vehicle will turn in that direction.
• WARNING: to ensure radio control reception,
the distance from the vehicle must not exceed
10 metres. When you lose connection, the
vehicle will stop, the radio control's LED will
start blinking again, and the vehicle's emergency
lights will turn on. In such a case, move closer to
the vehicle to restore the connection. The
vehicle will beep twice successively and the red
LED of the radio control will become steady
again.
• WARNING: the vehicle will turn off
automatically after 20 minutes of inactivity. To
reactivate it, repeat the start-up procedure
described above.
INDEPENDENT DRIVE MODE
32 • Turn the radio control off to save battery life. To
set the INDIPENDENT DRIVE MODE on,
remove the seat and press the switch
underneath it. The number 1 will be displayed on
the dashboard. Reposition the seat. The child can
now drive the vehicle in independent drive mode
