Specifications

• Mode of Operation: Demand and Continuous Flow
• Type of Protection Against Electrical Shock: Internally Powered
Equipment
• Degree of Protection Against Electrical Shock: Type BF
Applied Part
• IPX1 Classification According to the Degree of Protection Against
Ingress of Water: Drip Proof
• Equipment not suitable for use in the presence of
flammable mixtures
HELiOS Plus
(H300)
LOX capacity 0.9 lb (0,41 kg)
Gaseous equivalent 308 L
capacity
Weight, filled 3.6 lb (1,63 kg)
Weight, empty 2.7 lb (1,22 kg)
Height including handle 10.5" (267 mm)
Typical use time at 2 9 hours
LPM demand mode
Typical use time at 2 N/A
LPM continuous mode
Operating pressure 22 psi (152 kPa) 22 psi (152 kPa)
Normal evaporation rate 1.0 lb/day
(0,45 kg/day)
Standard flow control Continuous: off,
range .12, .25, .5, .75
Demand: off,
1, 1.5, 2, 2.5, 3,
3.5, 4

Warning Information

Important: Read this manual thoroughly before operating the H300/
H850.
RX Only.
WARNING: This device is not intended for life sustaining
use.
WARNING: If you feel the equipment is not operating
properly, call your health care provider. Do no attempt to
repair or adjust the unit yourself.
WARNING: Do not modify this equipment without
authorization from the manufacturer.
Caution: Use the H300/H850 Portable only as directed by
your doctor.
HELiOS Marathon
(H850)
2.0 lb (0,91 kg)
685 L
5.6 lb (2,54 kg)
3.6 lb (1,63 kg)
15.0" (381 mm)
22 hours
6.1 hours
0.85 lb/day
(0,39 kg/day)
Continuous: off,
1,2,3,4,5,6
Demand: off, 1.5,
2, 2.5, 3, 4
HELiOS Plus & Marathon
TM
The unit contains liquid oxygen which is extremely cold,
almost -184°C. Exposure to such a low temperature can
cause severe frostbite.
Liquid and gaseous oxygen, though nonflammable,
cause other materials to burn faster than normal. This
hazard, along with the low temperature of liquid oxygen,
warrants certain safety precautions.
Do not use or store your unit in an area where
combustible materials such as oils, greases, aerosol
sprays, lotions or solvents are present.
Do not smoke while operating the unit.
Do not use or store your unit within five feet of electrical
appliances, especially stoves, heaters, toasters, and hair
dryers.
Keep your unit in a well-ventilated area.
Do not carry the portable unit under your clothing.
In the event of an accidental tip-over, immediately but
cautiously return the unit into an upright position if
possible. If any liquid oxygen is escaping, leave the
area immediately and call your healthcare provider.
Do not touch frosted parts of any unit.
Do not store the HELiOS portable coupled to your
reservoir.
Do not allow untrained personnel to handle or operate
this device.
Use of this device is restricted on commercial
passenger and cargo air flights by the Federal Aviation
Administration.
Applicable EMC information can be found in the
Companion Portable Technical Service Manual at
www.CAIREmedical.com.
PN 21033264-C4 Rev A | User Manual
3 - ENG
