PUSH BUTTON FUNCTIONS

By default the display of the FNet Coordinator is OFF. An action on any push button
switches the display ON. The 2 push buttons allow the navigation in the following way:
• Up/Down: Short pressing allows to navigate up and down inside the list of
the menu list.
• ESC/Enter: Long pressing allows to go back to the previous menu or to enter to the
next menu.
MULTIFUNCTIONAL LCD AND NAVIGATION
The LCD dispose of max three display lines and is regrouped in 3 different menus to ensure the best compromise between
simplest use for the deployment, installation and configuration process. The different menus give access to all data required
for monitoring and maintenance of the FNet system.
• FNet Coordinator is actually in installation process and at least one endpoint has already been installed in the
Network. It indicates that the installation process has not been finished and still needs to run the procedure of
« Build/Sychronize the Network »
• It indicates the last GPRS signal level and will be actualized after each GPRS connection. If the GPRS connection
failed due to missing signal, the icon disappears. One blinking bar represents a very poor GRPRS signal.
One bar is low GPRS signal and 3 bars is high.
• Coordinator is equipped with GPRS-Modem option
• Coordinator is not equipped with AC 110V...230 V - 50/60Hz
• Coordinator is processing a task in the corresponding menu.
Interference Immunity :
Emitted Interference :
ETSI EN 301 489-1-V1.9.2 (2011-09)
ETSI EN 301 489-3-V1.6.1
ETSI EN 301 489-17-V2.2.1
EN 61000-3-2 (2006+A1 / 2009+A2 / 2009)
EN 61000-3-3 (2008)
ETSI EN 300 220-1 (V2.4.1)
ETSI EN 300 220-2 (V2.4.1)
EN 62311 (2008)
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
P a i r i n g R o u t e r/s
S c a n R o u t e r l i n k
I n s t a l l M I U
ESC
Up Down
ESC ENTER
