REPLACING LITHIUM BATTERIES
Batteries may only be replaced or exchanged by qualified staff. It is mandatory to follow the manufacturer procedure
assisted with the LCD display as described in the EquaScan FNet manuals. The connector only fits in one position in order
to guarantee installation with correct polarity. For this reason, no excessive force may be used when inserting the connector.
Caution: Risk of explosion if the batteries are not replaced properly. Replacement only by the same battery type and
recommended by the manufacturer. Note: Used batteries must NOT be disposed of with household waste.

NOTE ON DISPOSAL

Used electronic devices and their batteries must not be disposed of with normal household waste. We take all our products
back after use, free of charge, and dispose them accordingly. Do not expose to temperature outside of specifications. Do
not try to re-charge the lithium battery.
Characteristics
Wired Interface
Operating ambient temperature
Storage temperature
Transport temperature
Protection Class
External dimensions of the FNet Coordinator
Dimension
Material / Color
Weight
Radio specifications related to the endpoints
Protocol
Operating mode
Frequency Band
Transmitted power
Radio specifications of the FNet Coordinator
GPRS-Modem
Protocol
Modulation
Frequency Band
Transmitted power
Inductive Interface (Itron proprietary- ICP). Baud rate 19200
Between 0°C and +55°C
+0°C to +55°C < 1 year. Recommended below 30°C
Between -20°C and 70°C < 72 hours continuous
Temperature variation max. ±20°C/hour
IP43 (housing mounted)
Safety class 2 for mains AC 110V...230 V - 50/60Hz
( double/protective insulation)
(W x H x D) 214 x 257 x 65 mm
RAL 9016
1440 g (incl. package)
EN 13757-3/-4 wireless M-BUS
C2 Mode
868 MHz Band
Max < 25mW
Quad Band for 2G/3G functions (optional for Coordinator Devices only)
Itron proprietary protocol
GFSK-scheme( Gaussian Frequency Shift Keying)
433/868 MHz Band (between Coordinator and Router Devices)
433 MHz Transmitter power max 10mW
868 MHz Transmitter power max 25mW
