Tone table 2: Pre-selected tone details for voltage-free activation stages:
TONE
TONE FREQ/DESCRIPTION
No.
Stage 1
1 Alt Tones 800/970Hz at 1/4 sec
2 Sweeping 800/970Hz at 7 Hz
3 Sweeping 800/970Hz at 1 Hz
4 Continuous at 2850Hz
5 Sweeping 2400-2850Hz at 7Hz
6 Sweeping 2400-2850Hz at 1Hz
7
8 Sweep 1200-500Hz at 1Hz
9 Alt Tones 2400/2850Hz at 2Hz
10 Int Tone of 970Hz at 1Hz
11 Alt Tones 800/970Hz at 7/8Hz
12 Int Tone at 2850Hz at 1Hz
13 970Hz at 1/4 sec on 1 sec off
14 Continuous at 970Hz
15 554Hz for 0.1S/440Hz for 0.4S
16 Int 660Hz 150 mS on 150 mS off
17 Int 660Hz 1.8 sec on 1.8 sec off
18 Int 660Hz 6.5 sec on 13 sec off
19 Continuous 660Hz
20 Alt 554/440Hz at 1Hz
21 Int 660Hz at 7/8Hz
22 Int 2850Hz 150 mS on 100 mS off
23 Sweep 800-970Hz at 50Hz
24 Sweep 2400-2850Hz at 50Hz
25 3x970Hz pulses 0.5 off, 1.5 off
3x2850Hz pulses 0.5on/0.5off, 1.5 off
26
27 Int 3100Hz 0.32s on/0.68s off
28 Continuous 1400Hz
29 Spare / Custom tone
30 Spare / Custom tone
31 Spare / Custom tone
32 Spare / Custom tone
© MEDC 2016
Slow Whoop
SWITCH
Voltage free stage selection tone No.
SETTING
12345
Stage Stage
2
11111 T14 T10
11110 T14 T10
11101 T14 T10
11100 T14 T10
11011 T14 T10
11010 T14 T10
11001 T14 T10
11000 T14 T10
10111 T14 T10
10110 T14 T12
10101 T14 T10
10100 T14 T10
10011 T14 T10
10010 T28 T10
10001 T14 T10
10000 T14 T10
01111 T14 T10
01110 T14 T10
01101 T14 T10
01100 T14 T10
01011 T14 T10
01010 T14 T10
01001 T14 T10
01000 T14 T10
00111 T14 T10
00110 T14 T10
00101 T14 T10
00100 T14 T10
00011
00010
00001
00000
DC
Stage Stage
3 4 5
T11 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T6
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
T1 T8
AC
Stage
2
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
T28
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
T14
