Ignition Switch / Steering Lock - adiva AD3 200 Betriebsanleitung

IGNITION SWITCH
2
1
POS.
3
1
2
3
LIGHTS: enabled
STEERING LOCK
To lock the steering:
• Place the vehicle on the central or side stand.
• Turn the handlebar to the left.
• Push and turn the key to the position
"counter clockwise"
• Remove the key.

IGNITION SWITCH / STEERING LOCK

REF. FUNCTION
STEERING: locked
IGNITION: disabled
LIGHTS: disabled
STEERING: unlocked
IGNITION: disabled
LIGHTS: disabled
Saddle open: enabled
Trunk open: enabled
IGNITION: enabled
.
8
KEY
Can be removed
Can be removed
Cannot be removed
To Unlock:
Place the Vehicle on side or centre stand
Insert the key
Turn the key Clockwise to "off"
position
