EN
OCEAN P7
Program description
Warm water rinse:
DIP-switch 4
Serves to rinse the warm water pipe without the need for you to remain
within the sensor range of the shower.
Dip-switch 4 ON = Warm water rinse
Dip-switch 4 OFF = Warm water rinse function disabled.
User detection
When you step in front of the
shower, the system will detect
The illuminating icon
you.
begins to pulse slowly.
30-70 cm
28 Shower panel
function enabled (default setting).
Switch on warm water rinse
5 s after user detection the
user has time by tapping
inside the ON/OFF icon to start
the warm water rinse without
beeing in the active range.
Thereby the vertical line is
glowing in the symbol and the
external ring is pulsating.
WimTec OCEAN P7
It is recommended,
to combine the warm
water rinse not with
the fully automatic
Operation
After activation, water will
flow for 30 s plus the configu-
ON
OFF
1 2 3 4 5 6
red shut-off delay without the
need for you to remain within
the sensor range; it will then
automatically shut down again.
If you enter the sensor range
for at least 5 s during these
30 s, the shower will resume
normal operation.
Warmlauf:
OFF
ON
6 5 4 3 2 1
Reinigungsstopp:
OFF
!
ON
6 5 4 3 2 1
Hygienespülung:
OFF
ON
6 5 4 3 2 1
program!
Halbautomatik:
OFF
ON
6 5 4 3 2 1
Vollautomatik:
OFF
ON
6 5 4 3 2 1
Manuell:
OFF
ON
6 5 4 3 2 1
