Maintenance and overhaul (outside of warranty period)
For models with active cooling (see technical data):
Make sure periodically that the air inlet/outlet is not affected.
If illuminant replacement is necessary:
Screen
1.
Loosen the fixing screws with a screwdriver
2.
Take off the end cap
3.
Take the screen carefully out of the profile by pulling towards the opened cap
4.
Take out the luminaire by pulling towards the opened cap
5.
Put in the new luminaire
6.
Assembly in reverse order
ATTENTION!
Make sure that you do not clamp or damage any wires!
Your product is designed and produced with high quality materials and components that are recycla-
ble and can be reused. This product is to be disposed of separately from the household waste. Please
dispose of the product at your local collection point or in the recycling centre. Please help preserving
the environment we live in.
We take care of an eco-friendly disposal of your old equipment, directly ask the SETOLITE team!
14
Illuminant replacement (only Flex 640)
Illuminant PL-L
Lower end cap with cable inlet
Disposal
Return old equipment
Upper end cap (with fan - not all versions)
Fixing screw 4x
