Adjustment of the modules
(suspended operation)
The ALDEBARAN 360 GRAD FLEX luminaire has
®
4 single light modules that can be adjusted via
mechanics for the requirements of the worksplace.
Therefore, the modules can be adjusted to the
required position between 0-70° of inclination
after unlocking.
1. Unlocking of the modules
Before you can adjust the inclination of the
luminaire (8-fold screening), the magnetically
locked modules need to be unlocked, therefore
grab every single light module with both hands
at the sides and pull it towards the body.
Picture 1 (transport mode)
2. Adjusting the luminaire's inclination (sus-
pended operation)
In order to adjust the required inclination, pull
out the upper detent pin and lower the lumi-
naire to the required inclination. For fixing of
the adjusted position, the detent pin has to lock
into the default hole.
ATTENTION! Risk of injury!
The detent pin must lock into the required positi-
on. That way, you avoid accidents and injuries.
3.

Folding up the luminaire

The luminaire can be put again into its initial
position by carrying out the steps described
above in reverse order.

Handling

The ALDEBARAN
controlled via the two toggle switches and the rotary
knob (only with dimmable versions) on the control
unit. The control unit is integrated into the supply
line.
With every toggle switch, 2 light modules are switched
(ON/OFF).
By turning the potentiometer clockwise, the illumi-
nance level can be increased, counter clockwise lowers
the illuminance level (only with dimmable versions).
Picture 2
Error
1 light module
without function
Upper detent pin
2 light modules
without function
All 4 light
modules without
function
Luminaire cannot
be dimmed
Extreme discre-
pancy in the
Holes
brightness of one
light module
For cleaning the plastic / metal parts, do not use any
solvents, alcohols or other chemicals. For removing
dirt, dust, oil, grease etc., use a soft, dry and lint-free
cloth.

Operation

360 GRAD FLEX luminaire can be
®
Toggle switches ON / OFF
Control unit

Malfunction

Possible
cause
Defect in light
module
Toggle switch
OFF
No voltage
Defect of the
rotary knob
Defect of the
active cooling

Cleaning and care

Potentiometer
Solution
Ask your trained
electrician or the
manufacturer
Check the control
elements (toggle
switches)
Check the voltage
supply
Ask your trained
electrician or the
manufacturer
Ask your trained
electrician or the
manufacturer
