1. Technical Data
1.1. Article numbers
Electric drain cleaning machine
Drain cleaning cable Ø 8 x 7.5 m
Drain cleaning cable Ø 10 x 10 m
1.2. Capacity
Removal of pipe blockages,
e.g. lavatory, sink, shower, bathtub drains
For pipes
1.3. Electric data
230 V, 50–60 Hz, 620 W, 2.9 A; or 110 V, 50–60 Hz, 620 W, 5.8 A
1.4. Dimensions
1.5. Weight
1.6. Noise information
Emission at workplace
1.7. Vibrations
Weighted effective value of acceleration

2. Operation

Attention! Only operate the tool with both hands, always hold the thrust
handle (1) and machine handle (2) tightly. Note the reaction torque of
the drive machine!
Set the direction ring (3) to cable thrust (arrow up). Press the push-
button switch slowly so that the drum turns. Turn the thrust handle (1)
clock wise until the pipe cleaning cable pushes forward automatically.
Push the pipe cleaning cable forward about 20 cm and insert in the
pipe to be cleaned. Do not tighten the thrust spindle too tight other wise
the pipe cleaning cable may block and damage the device. Keep a
maximum distance of 20 cm between the end of the pipe/drain and the
thrust housing. If the distance is too great the pipe cleaning cable may
loop (danger of injury). Reduce the speed if you encounter resistance.
Only push the pipe cleaning cable forward to an extent that at least 2
windings remain in the drum when cleaning. If the pipe cleaning cable
is pushed further forward, the motor can no longer retract the cable.
The pipe cleaning cable must then be pushed back about 50 cm by
hand. Then the automatic return starts working again.
After clearing the blockage, set the direction ring (3) to return (arrow
down). Keep a distance of at least 20 cm between the end of the pipe/
drain and the thrust housing. If the pipe cleaning cable protrudes from
the end of the pipe/drain, shut down the drive machine immediately.
Attention! The club head moulded to the pipe cleaning cable may not
get into the thrust gear. The drive machine otherwise blocks abruptly
and the thrust gear, club head and pipe cleaning cable are destroyed.

3. Maintenance

3.1. Maintenance
Pull the mains plug before maintenance work! Keep machine clean.
3.2. Inspection/Repair
Pull the mains plug before inspection/repair work! This work may only
be performed by authorised experts or by trained personnel.
The motor of the drive machine has carbon brushes. These are subject
to wear and must therefore be inspected respectively replaced from
time to time by an authorised ROLLER after-sales service facility.
4. Manufacturer's Warranty
The warranty period shall be 12 months from delivery of the new
product to the first user. The date of delivery shall be documented by
the submission of the original purchase documents, which must include
the date of purchase and the designation of the product. All functional
defects occurring within the warranty period, which are clearly the
consequence of defects in production or materials, will be remedied
free of charge. The remedy of defects shall not extend or renew the
warranty period for the product. Damage attributable to natural wear
and tear, incorrect treatment or misuse, failure to observe the opera-
tional instructions, unsuitable operating materials, excessive demand,
use for unauthorized purposes, interventions by the customer or a third
party or other reasons, for which ROLLER is not responsible, shall be
170020
excluded from the warranty.
170200
Services under the warranty may only be provided by customer service
170205
stations authorized for this purpose by ROLLER. Complaints will only
be accepted if the product is returned to a customer service station
authorized by ROLLER without prior interference in an unassembled
condition. Replaced products and parts shall become the property of
Ø 20–50 (75) mm
ROLLER.
The user shall be responsible for the cost of shipping and returning
the product.
The legal rights of the user, in particular the right to make claims against
470x290x200 mm
the seller under the warranty terms, shall not be affected. This manu-
5.3 kg
facturer's warranty only applies for new products which are purchased
in the European Union, in Norway or in Switzerland.
80 dB(A)
This warranty is subject to German law with the exclusion of the United
Nations Convention on Contracts for the International Sales of Goods
(CISG).
2.5 m/s
2
5. EC declaration of conformity
ROLLER declares that the products decribed in this user manual comply
with corresponding directives 98/37/EG, 89/336/EWG and 73/23/EWG.
Correspondingly this applies to the following norms:
DIN EN ISO 12100-1, DIN EN 12348, DIN EN 50144-1,
DIN EN 55014-1, DIN EN 55014-2, DIN EN 60204-1, DIN EN 60335-1,
DIN EN 60335-2-45, DIN EN 60745-1, DIN EN 60745-2-9,
DIN EN 60745-2-11, DIN EN 61000-3-2, DIN EN 61000-3-3,
DIN EN 61029-1, DIN EN 61029-2-9.
Waiblingen, 01.01.2011
Albert ROLLER GmbH & Co KG
Manufacturer of Tools and Machines
D-71332 Waiblingen
Rainer Hech
