Declaration of Conformity
We declare under our sole responsibility that
the product described under "Technical Data" is
in conformity with the following standards or
standardization documents: EN 60745 accord-
ing to the provisions of the directives
2004/108/EC, 98/37/EC (until Dec. 28, 2009),
2006/42/EC (from Dec. 29, 2009 on).
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Dr. Egbert Schneider Dr. Eckerhard Strötgen
Senior Vice President Head of Product
Engineering Certification
17.03.2008, Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Assembly
Delivery Scope
ANGLE EXACT 2 | 3 | 6 | 7 | 8 | 15 | 17 | 23 | 30
This industrial cordless angle wrenches are sup-
plied without application tools, angle head,
straight head, Ni-Cd battery pack, charger, con-
stant voltage regulator or voltage adapter. The
voltage adapters are to be used exclusively for
connection of Bosch industrial cordless angle
wrenches to the 4EXACT constant voltage regu-
lator.
ANGLE EXACT 14CF | 22CF | 29CF
These industrial cordless angle wrenches are
supplied without application tools, flat drive,
straight head, intermediate flange, Ni-Cd bat-
tery pack, charger, constant voltage regulator or
voltage adapter. The voltage adapters are to be
used exclusively for connection of Bosch indus-
trial cordless angle wrenches to the 4EXACT
constant voltage regulator.
Bosch Power Tools
ANGLE EXACT 7 – 900 | 10 – 650 | 14 – 420
These industrial cordless angle wrenches are
supplied without application tools, angled drive
head, straight drive head, Ni-Cd battery pack
and charger.
These power tools are not suitable for operation
with constant voltage regulator.
ANGLE EXACT 25 – 250 | 30 – 380 | 40 – 280 |
50 – 210
This industrial cordless angle wrenches are sup-
plied with angle head, but without application
tools, Ni-Cd battery pack and charger. These
power tools are not suitable for operation with
constant voltage regulator.
Operating and Storage Environment
The device is suitable exclusively for oper-
ation at enclosed work sites. For trouble-
free operation of the device, the allowed
ambient temperature should lie between – 5 °C
and +50 °C (23 °F and 122 °F) at an allowed
relative humidity of between 20 and 95 %, free
of dew.
In order to avoid damage to the battery cells,
the battery pack should be stored within a tem-
perature range between 0 °C (32 °F) and 45 °C
(113 °F).
Mounting the Angled Screw Head
ANGLE EXACT 2 | 3 | 6 | 7 | 7 – 900 | 8 |
10 – 650 | 14 – 420 | 15 | 17 |
23 | 30
On these industrial cordless angle wrenches, a
fitting angled screw head (see "Angled drive
head", page 30) has to be mounted first.
Make sure that the rotational direction
switch is in the middle position (switch-on
lock) or that the battery pack has been re-
moved from the power tool before mount-
ing a screw head, adjusting or dismounting.
Hold the power tool with the open-end spanner 6
by the spanner flats 5 of the angled head flange.
Never clamp the tool by the housing shells!
