must be filed down using a flat file. The
depth limitation should be set back ap-
proximately 0.65 mm compared to the
cutting tooth. After filing the depth limita-
tion down, round it off by slightly sliding
forward.
• The chain has become worn down and
must be replaced by a new saw chain
when only around 4 mm of the cutting
tooth remains.
• Adjust the transparent cover regularly
in order to compensate for wear on the
grinding disc (see chapter „Initial start-
up").
Maintenance and
cleaning
Disconnect the plug before adjust-
ment, maintenance or repair.
Have any work not described
in these instructions carried
out by a specialist workshop.
Use only original components.
Allow the equipment to cool
before carrying out any main-
tenance and cleaning work.
There is a risk of burns.
Before each use, check the equipment for
obvious defects such as loose, worn or dam-
aged components and check that screws or
other parts are sitting correctly. In particular,
check the grinding disk (
damaged parts.
Cleaning
Do not use cleaning agents or sol-
vents. Chemical substances may
attack plastic parts of the equipment.
Never clean the equipment under
running water.
124
18). Replace
• Clean the equipment thoroughly after
each use.
Clean the ventilation openings (
and the surface of the equipment with
a brush or cloth.

Changing the grinding disc

(Fig.3)
Ensure that the rotation speed sta-
ted on the grinding disc is the same
or higher than the nominal rotation
speed of the device.
Ensure that the disc dimensions
match those of the device.
4
Switch off the equipment and dis-
connect from the mains.
Allow the equipment to cool.
Use the tools included in delivery
to change the grinding disc (see
Fig. 1 nos. 23 + 24 + 25).
1. Unscrew the grinder housing. To do
this, remove the fixing bolt, washer and
nut (19).
19 8
6
23
18
21)
5
26
27
7
