FIG IV-B : Installing the drive roller.
• Choose the correct diameter reel for the type of wire. The visible diameter indicated on the roller when fitted in
place is the diameter currently in use (ie. 0.8mm is visible for use with 0.8mm wire).
FIG IV-C : To select the adjustment of the drive rollers, proceed as follows :
• Loosen the drive roller knob as far as possible.
• Insert the wire until it exits the other side by about 2cm, tighten the knob again slightly.
• Start the motor by pressing the trigger of the torch.
• Tighten the knob (fig IV-C) whilst pressing the trigger until the wire starts to move.
Nb : When welding with Aluminium, use the minimum possible pressure to avoid crushing the wire
• Pull the wire out of the end of the torch by approximately 5cm, then attach the contact tip suitable for the wire used
and then the nozzle (fig IV-E).
The SPARK MIG 140 and 160 machines can accommodate coils of 100 or 200mm diameter.
Below are the different combinations possible :
Spark MIG
140
steel/
0.6/0.8
stainless
steel
Alu*
0.8
No Gas
0.9
Electrodes
-
* We recommend a teflon sheath (ref. 041578) and special Aluminium contact tip (Ø 0.8 ref. 041059 - Ø 1.0 ref.
041066)
To help you select the diameter of wire suitable for the job you want to perform, refer to the table on page 4 (FIG
III).
GAS COUPLING
- Connect a pressure regulator to the gas bottle. Connect the welding machine using the pipes supplied, and place
the two clamps to avoid leakages.
- Set the gas flow by adjusting the dial located on the pressure regulator.
NB : to help facilitate the adjustment of the gas flow, operate the drive rollers by pressing the trigger of the torch
(ensure that the drive roller is completely loose so the wire is not fed through).
This procedure does not apply to "Gasless" welding mode.
CONTROL PANEL (FIG. VI)
DIRECTIONS OF USE (FIG V)
Spark MIG 140/160 feature allows you to adjust the voltage and the wire speed.
Use the SMART table to find the correct settings based on the type of wire, and the thickness of the metal workpiece.
Then based on the recommendation indicated, simply select :
• The voltage (buttons A/ B & min/max)
• Wire speed - adjust the regulator (3) to the colour zone indicated.
Examples :
To weld 0.8mm thick steel, use 0.6 mm diameter steel wire :
• Move button (1) to the « A » position
• Move button (2) to the « min » position
• Move the regulator (3) to the zone of lightest colour and adjust « by sound » if required
ADVICE AND THERMAL PROTECTION
• Respect the normal rules of welding
• Leave the machine plugged in after welding to allow it to cool
SPARK MIG
160
gaz
0.6/0.8/1.0
Argon +
CO2
0.8/1.0
Pure Argon
0.9/1.2
-
-
-
Spark MIG
1- Voltage selection button A / B
2- Voltage selection button min/max.
3- Wire speed regulator.
4- « SMART » settings table MIG/MAG
5- Thermal Protection light.
6- positions switch
EN
9
