Attention: Important Operational Information. Please Read Before Installation.
• The loudspeaker may be operated only with the system-synchronized crossover and under
observance of the specified rated output power.
• Interchanging the woofer and tweeter connections will lead to immediate destruction of the tweeter.
• Beginning operation without the crossover, for example with an active crossover or non-system
crossover, will result in damage to the loudspeaker.
• The tweeter is intended for active operation without passive crossover. Disregarding this will
thermally damage the tweeter by feeding it at too-high power levels.
• When connecting the loudspeaker, crossover, and amplifier it is absolutely necessary to employ the
same polarity. Interchanging the polarity produces an unnatural sound lacking bass reproduction.
• The component systems are acoustically synchronized as one unit. Supplementation through an
auxiliary loudspeaker or trade out with a larger woofer is not possible as this would change the
overall frequency response or impedance of the system. An overload of the crossover or a single
loudspeaker would then be unavoidable.
• The opening of the crossover for the purpose of altering the parts or function, for example bi-amping,
is considered foreign interference and grounds for termination of the warranty
• For the purpose of technical safety, the loudspeaker should only be attached with the included self-
tapping screws. We accept no liability for use of alternative methods of attachment.
Fastening for Woofer:
woofer 100 / 130 / 165 mm ∅ (screw terminal)
2 / 4 pieces
8 pieces self-tapping screw
8 pieces washer
8 pieces self-tapping nut
Fastening for Tweeter (not for PRO):
2 pieces SL-T25 (cable connection)
2 pieces flush mount
2 pieces angle mount
2 pieces screw
2 pieces threaded bolt
4 pieces self-tapping screw 3.9 x 19
2 pieces washer
2 pieces nut
2 pieces U-bracket
Fastening for Crossover:
2 pieces crossover
4 pieces self-tapping screw 3.9 x 19 DIN 7981 black
Miscellaneous:
1 piece installation manual

Contents and Detail of Parts

M4
3.9
M4 x 5
M4 to M5
M4
M5
24
B
G
H
I
J
M
O
P
Q
R
T/U
V
W
X/X1
Z
