Language; Cycles; Cleaning; General Cleaning - Melitta CAFFEO 76 Bedienungsanleitung

13 13 Setting functions Setting functions

13.6 Language

The appliance is supplied with the following
languages: English, German, French, Dutch,
Danish and Swedish. Proceed as follows to
select the desired language:
½ Turn the function controller (20) to
"F" and confirm with Start (22).
½ Keep on pressing the selection keys (19)
until "Language" is selected; then press
Start (22).
½ Use the selection keys (19) to set the desired
language and confirm with Start (22).
½ The setting is saved and you are returned
to the main menu.
14

Cleaning

14.1 General cleaning

Wipe the outer surfaces of the machine with
a damp cloth.
Fig. P When the drip tray (8) is full (as shown
by the level indicator (10)), remove and empty
it. For thorough cleaning, the drip grate (9)
can be removed from the drip tray (8). Use
only warm water and non-scouring agents to
clean the parts. Also clean the level indicator
(10) to ensure its continued working. Simply
pull it out. After cleaning, put all parts back
together again. Only use the machine when
it is completely re-assembled.
Occasionally wipe the Bean Select bean
container (2) with a damp cloth to remove
any coffee oil or grease.
Regularly empty the coffee grounds container
(11) – at least 1x a day. For this, push the coffee
outlet (12) into the upper position and pull
out the coffee grounds container to the front.
Dispose of the coffee grounds and rinse out
the container with water. The machine is only
ready for use when the coffee grounds
container has been inserted back into the
appliance.
Tip: Throw coffee grounds away with organic
waste or onto the compost heap.
31

13.7 Cycles

The function "Cycles" displays the total number
of brewing cycles. You can also see how many
brews are still to elapse before de-scaling or
cleaning is required.
½ Turn the function controller (20) to
"F" and confirm with Start (22).
½ Keep on pressing the selection keys (19)
until "Supplies" is selected; then press
Start (22).
½ The total number of cycles appears first.
Press the start key again for information on
the next de-scaling and cleaning cycles.
½ Confirm again with the start key and you
are returned to the main menu.

14.2 Cleaning the Easy Cappuccino

Milk deposits in the Easy Cappuccino (14) can
be easily removed. Unscrew the lower base
of the Easy Cappuccino. Remove the whisk
wheel by pressing it from the top out of the
steam pipe, Fig. Q. Traces of milk on the steam
pipe and whisk wheel can now be rinsed,
wiped off or removed in the dishwasher. Then
put back the whisk wheel into the steam pipe
from below until it snaps into place. Secure
both to the Easy Cappuccino.
Make sure the seal of the Easy Cappuccino
always sits firmly.
14
Cleaning

14.3 Cleaning the grinder

The grinder does not usually need to be
cleaned. Now and again, larger residues can
be removed with a small brush. Never clean
the grinder with water.

14.4 Integrated rinsing programme

The appliance can be rinsed individually at
any time. Proceed as follows:
½ Turn the function controller (20) to
"Clean/Decalcify". Use the selection keys (19)
to select "Rinsing" and confirm with Start (22).
½ "Appliance is rinsing" appears in the display
and the rinsing symbol flashes.
½ When the process has ended, "Rinsing
completed" appears.
½ By pressing the Start key again, you are
returned to the Clean/Decalcify menu.
The appliance is ready for operation again.

14.5 Integrated cleaning programme

This programme is for the complete removal
of residues and traces of grease which cannot
be removed by hand. We recommend monthly
cleaning or after some 200 brewed cups – at
the latest when the appliance requests you to
do so. "Clean!" appears in the display and the
cleaning symbol lights up.
Tip: Use the specially developed Melitta ®
cleaning tabs for fully automatic coffeemakers
and single cup machines, as these are adapted
® ®
exactly to your Melitta CAFFEO .
½ Turn the function controller (20) to
"Clean/Decalcify". Use the selection keys (19)
to select "Cleaning" and confirm with
Start (22).
½ Fill the water reservoir (7) to capacity
(1.5 litres).
½ Fig. R Set the coffee bean container (2) to
ground coffee operation and insert the
cleaning tab into the ground coffee chute.
After inserting, confirm by pressing the start
key (22).
½ Empty the coffee grounds container and
replace. Then pull out the container (11) to
the middle of the drip tray, where it can
collect the cleaning water.
½ Now press the start key (22).
The cleaning programme can no longer be
interrupted. There are 6 rinsing cycles with
breaks. The programme lasts some 8 minutes.
"Cleaning in progress" appears in the display
during the whole operation.
When the programme is over, empty the
coffee grounds container and replace
completely. After inserting, confirm by
pressing the start key (22). Now confirm
the "Cleaning completed" message by
pressing the start key (22).
After putting into serving operation, the
coffeemaker is ready for use again.

14.6 Cleaning the brewing unit

We recommend cleaning the brewing unit
from time to time. This is how to proceed:
½ Shut down the appliance.
½ Fig. S Open the service door (6).
½ Fig. T Press the red safety lever on the right
upwards until it stops.
½ Fig. U Keep the red safety knob at top left
pressed with your left hand. At the same
time, use your right hand to press down
the interlocking key at the front of the
brewing unit. Pull the brewing unit out to
the front, Fig. V.
½ Fig. W Turn the red handle at the side of
the brewing unit to open it.
½ Now you can thoroughly clean the brewing
unit under running water.
½ After cleaning, turn back the red handle.
½ Fig. T Put the brewing unit back into the
appliance, press down the safety lever and
close the service door.
½ The appliance can be switched on again.
32
