W+
1:
Pump housing
2:
Clamp ring
3:
O-ring
4:
Impeller
5:
Cap nut
6:
Shaft
7:
Rear flange
8:
Pin
9:
Extension frame
Section 1 Standard seal
Section 2 Seal with liquid/steam flushing
10:
Rotor ring
11:
Stator ring
12:
O-ring
13:
O-ring
14:
Seal cover
15:
Rotor ring
16:
Stator ring
17:
O-ring
18:
O-ring
19:
Drain pipe
20:
Seal cover
