Anleitung RT-JS 85_SPK1:_
GB
Important!
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety regulations with due care. Keep this manual in
a safe place, so that the information is available at all
times. If you give the equipment to any other person,
hand over these operating instructions and safety
regulations as well. We cannot accept any liability for
damage or accidents which arise due to a failure to
follow these instructions and the safety instructions.

1. Safety information

Please refer to the booklet included in delivery for the
safety instructions.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1)
1. Knurled screw for speed control
2. Locking button
3. ON/OFF switch
4. Holder for saw blades
5. Power cable
6. Adapter for dust extraction system
7. Adjustable soleplate
8. Selector switch for pendulum action
9. Dial scale for soleplate
10. Guide roller
11. Parallel stop
12. Saw blade
13. Locking screws for parallel stop
14. Blade holder
15. Safety guard
16. LED lamp
17. ON/OFF switch for LED lamp
18. Locking screw for soleplate
12
15.09.2008 12:49 Uhr Seite 12

3. Proper use

The jigsaw is designed for sawing wood, iron, non-
ferrous metals and plastics using the appropriate saw
blades.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

Mains voltage:
Power input:
Stroke speed:
Stroke height:
Cutting depth, wood:
Cutting depth, plastic:
Cutting depth, iron:
Miter cut:
Protection class:
Weight:
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L sound pressure level
pA
K uncertainty
pA
L sound power level
WA
K uncertainty
WA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
230 V~ 50 Hz
750 W
800 – 3,000 min -1
23 mm
85 mm
12 mm
8 mm
up to 45° (left and right)
II /
2.5 kg
87,3 dB(A)
3 dB
98,3 dB(A)
3 dB
