Technical specifications
Electromagnetic compatibility (EMC)
Emission
Immunity on signal cables
Immunity to discharge of static electricity
Immunity to radiated RF
UL/CSA approval
Mechanical environmental conditions
Vibration
Shock
Temperature (operation)
Transport and storage temperature
Humidity (operation)
Fast temperature change in operation
Fast temperature change during storage/transport
Damp heat, cyclic during storage/transport
16
Class B to EN 55022
FCC class B
+/- 2 kV
to IEC 61000-4-5, surge
+/- 1 kV
to IEC 61000-4-3, burst
+/- 6 kV, contact discharge
to IEC 61000-4-2
• 10 V/m at 80 MHz – 2 GHz to IEC 61000-4-3
10 V/m with 80 % amplitude modulation at 1 kHz
•
10 kHz – 80 MHz to IEC 61000-4-6
•
Safety
The CP 5621 meets all requirements for add-on modules
according to the cULus approval.
Tested to IEC 60068 2 6: 10 ... 58 Hz,
Amplitude: 0.075 mm, 58 ... 500 Hz;
Acceleration: 10 m/s2, 10 cycles/axis
Tested to IEC 60068 2 27;
Half sine: 50 m/s2 (5 g), 30 ms,
100 shocks/axis
Climatic conditions
Tested to IEC 60068 2 1, 60068-2-2:
+5 ... +55 °C,
Temperature change: max. 10 K/h
-20 ... +60 °C,
Temperature change: max. 20 K/h
Tested to EN/IEC 60068-2-78:
5 ... 85% at 30 °C (no condensation)
Tested to IEC 60068-2-14:
+5 ... +55 °C, 5 cycles
Tested to IEC 60068-2-14:
-20 ... +60 °C, 2 cycles
Tested to EN/IEC 60068-2-30:
25 ... 55 °C at 95 % (no condensation)
Operating Instructions (Compact), 02, A5E01156749
CP 5621
