Technical specifications

CP 5621
The following technical specifications apply to the CP 5621 communications processor:
Module format
Dimensions (H x D) in mm
Weight
Card connector principle
Bus interface
Operating voltage
Rated voltage (limit values)
Current consumption at rated voltage
At 12 V DC
At 3,3 V DC
Transmission speed
Connection to PG/PC
Plug-in connector
Transmission method
Mode of the MPI/DP interface
CP 5621
Operating Instructions (Compact), 02, A5E01156749
Construction
PCI Express card - standard height and half length
111 x 129
Approx. 100 g
PCI Express connector
PCI Express V1.0a, plug and play
Voltage
Safety extra low voltage (SELV) to EN 60950
12 V and 3.3 V DC
max. 180 mA
max. 400 mA
Data transmission
9.6 Kbps to 12 Mbps
Interfaces
PCI Express x1; can also be operated in x4, x8 or x16 slots.
9-pin D-sub socket strip with screw lock
RS-485 floating within SELV limits
Floating (interface signals), non-floating (cable shield)
