We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Number of DMX channels:
DMX-512 connection:
Number of 5mm LEDs:
Beam angle:
Sound-control:
Type of LEDs
Maximum ambient temperature T
Maximum housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
Fuse:
Dimensions (LxWxH):
Weight:
Accessories:
EUROLITE TH-50H theatre-hook f.50mm pipe
Safety bond AG-5 3x600mm up to 5kg
Please note: Every information is subject to change without prior notice. 25.05.2011 ©
230 V AC, 50 Hz ~
30 W
6
3-pin XLR
228
15°
via built-in microphone
5mm
:
45° C
a
(steady state):
60° C
B
0.50 m
0.10 m
F 1 A, 250V
315 x 470 x 175 mm
4 kg
No.
58000653
58010360
25/25
00039785.DOC, Version 1.2
