Noise/Vibration Information

Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 85 dB(A); Sound power level 96 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values (triax vector sum) determined accord-
ing to EN 60745:
Hammer drilling into concrete: Vibration emission value
2
a =13 m/s , Uncertainty K=3 m/s
h
Drilling into metal: Vibration emission value a
2
certainty K=1.5 m/s ,
Screwdriving: Vibration emission value a
2
tainty K=1.5 m/s .
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under "Technical Data" is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2004/108/EC,
2006/42/EC.
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Dr. Egbert Schneider Dr. Eckerhard Strötgen
Senior Vice President Head of Product
Engineering Certification
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
08.03.2011
Assembly
 Before any work on the machine (e. g., maintenance,
tool change, etc.) as well as during transport and stor-
age, set the rotational direction switch to the centre
Bosch Power Tools
Battery Charging (see figure A)
 Use only the battery chargers listed on the accessories
Note: The battery is supplied partially charged. To ensure full
capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.
2
,
The lithium-ion battery can be charged at any time without re-
2
=4 m/s , Un-
h
ducing its service life. Interrupting the charging procedure
does not damage the battery.
2
<2.5 m/s , Uncer-
h
The lithium-ion battery is protected against deep discharging
by the "Electronic Cell Protection (ECP)". When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.
tomatically switched off. The battery can be damaged.
To remove the battery 10, press the battery unlocking button
18 and pull the battery out of the power tool toward the rear.
Do not exert any force.
For charging, the battery 10 can also remain in the power
tool. During the charging procedure, the power tool cannot be
switched on. Press the On/Off switch 8 to check the charge
condition of the battery, see Section "Battery Charge-control
Indication".
The battery is equipped with a NTC temperature control
which allows charging only within a temperature range of be-
tween 0 °C and 45 °C. A long battery service life is achieved
in this manner.
Observe the notes for disposal.
Selecting Tools
For hammer drilling, SDS-Quick tools are required.
For drilling without impact in wood, metal, ceramic and plas-
tic, a suitable SDS-Quick tool or an application tool with hexa-
gon shank can be used.
For screwdriving, use only screwdriver bits with ball catch 14
(DIN 3126-E6.3). Other screwdriver bits 13 can be inserted
via a universal bit holder with ball catch 12.
A selection of suitable application tools can be found in the
Accessories Overview at the end of these instructions.
Changing the Tool
Due to their working principle, SDS-Quick drilling tools move
freely. This results in radial run-out at no-load. However, this
has no effect on the accuracy of the drill hole, as the drill bit
centres itself during drilling.
position. Unintentional actuation of the On/Off switch can
lead to injuries.
page. Only these battery chargers are matched to the lith-
ium ion battery of your power tool.
Do not continue to press the On/Off
WARNING
switch after the machine has been au-
The SDS-Quick tool holder allows for simple
and convenient changing of drilling tools with-
out the use of additional tools.
