4. Mounting the side bank / Ceramik

4.1 fixing the side bank

It is recommended that the side bank with the corpus to connect (see Figure
12). Bank side to the desired position (can be left or right mounted). From the
inside, the pre-drilled holes (No. 1) marking of the body. Marked holes with a
6 mm steel drill drilling, and assemble with the attached screws.
No. 1
picture 12
The manuals for the tiles, is in the glazed tile kit!
We reserve the right to make changes which relate to technical advances and / or to an improve-
ment in quality. We accept no liability for printing errors and changes which occur after printing.
