Dear MAGNAT Customer,
The EDITION MONO car hi-fi power amplifier will enable you to satisfy your high demands on sound
reproduction in your car. With its impressive deep-bass power reserves, low harmonic content and neutral
reproduction, the EDITION MONO takes car hi-fi to new heights. The amplifier is characterized by low operating
current, rapid switching capabilities and excellent temperature stability. Experience and enjoy how this high-
tech machine perfectly reproduces magnificent sound.
Please read all of the owner's manual before installing and using the amplifier.
1.

TECHNICAL DATA

Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 324, B+=14.4V)
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 324, B+=14.4V)
Loudspeaker impedance
Frequency response
Total harmonic content (DIN 45 403)
Weighted noise distance (IEC A)
Input sensitivity LOW LEVEL INPUT
Input impedance LOW LEVEL INPUT
Low-pass filter
Subsonic filter
Bass boost
Supply
Fuse
Sizes (W x H x D)
Weight
SUBJECT TO TECHNICAL CHANGE
2. FEATURES
· Complementary push-pull final stage
· Stable at 2 ohms
· Low-pass (subwoofer) and subsonic filter with infinitely adjustable separating frequencies
· Infinitely variable bass equalisation
· Adjustable input sensitivity
· Electronic protective circuit against short circuiting, DC offset and excess temperature
· Mute switch for suppressing switch-on crackle interference
· Low-level outputs (cinch jacks) for connecting additional amplifiers
· Status indicator (green LED) and overload indicator (red LED)
· Remote control for volume control
3.

IMPORTANT INSTALLATION INFORMATION

· This appliance may only be connected to a 12 volt system with negative ground.
· The heat radiated when the amplifier is used means that sufficient air circulation is required at the place
of installation. It is very important that the cooler's cooler ribs do not contact any metal plating or any
surfaces which could impair air circulation. The amplifier may not be installed in small confined spaces or
spaces without air circulation (e.g. spare wheel recess or under the vehicle carpeting). Installation in the
boot is recommended.
· Install the amplifier in such a way that it is protected as far as possible against vibrations and dust and dirt.
GB
EDITION MONO
800 W on 4 Ohm
225 W on 4 Ohm
1400 W on 2 Ohm
350 W on 2 Ohm
2 – 8 Ohm
5 – 300 Hz (-3 dB)
< 0.08 % (1 kHz)
> 100 dB
0.4 – 4 V
20 kOhm
40 – 300 Hz, 12 dB per octave
10 – 40 Hz, 12 dB per octave
0...12 dB at 45 Hz
+12 V (10 – 15 V), minus to ground
2 x 25 A
345 x 57 x 236 mm
3.1 kg
